EUROPEAN STANDARD EN IEC 60358-1

NORME EUROPÉENNE
EUROPÄISCHE NORM February 2026
ICS 29.120.99; 29.240.99; 31.060.70 Supersedes EN 60358-1:2012; EN 60358-
1:2012/AC:2013
English Version
Coupling capacitors and capacitor dividers - Part 1: General
rules
(IEC 60358-1:2025)
Condensateurs de couplage et diviseurs capacitifs - Partie Kopplungskondensatoren und kapazitive Teiler - Teil 1:
1: Règles générales Allgemeine Bestimmungen
(IEC 60358-1:2025) (IEC 60358-1:2025)
This European Standard was approved by CENELEC on 2026-01-27. CENELEC members are bound to comply with the CEN/CENELEC
Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration.
Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC
Management Centre or to any CENELEC member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation
under the responsibility of a CENELEC member into its own language and notified to the CEN-CENELEC Management Centre has the
same status as the official versions.
CENELEC members are the national electrotechnical committees of Austria, Belgium, Bulgaria, Croatia, Cyprus, the Czech Republic,
Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, the
Netherlands, Norway, Poland, Portugal, Republic of North Macedonia, Romania, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland,
Türkiye and the United Kingdom.

European Committee for Electrotechnical Standardization
Comité Européen de Normalisation Electrotechnique
Europäisches Komitee für Elektrotechnische Normung
CEN-CENELEC Management Centre: Rue de la Science 23, B-1040 Brussels
© 2026 CENELEC All rights of exploitation in any form and by any means reserved worldwide for CENELEC Members.
Ref. No. EN IEC 60358-1:2026 E

European foreword
The text of document 33/732/FDIS, future edition 2 of IEC 60358-1, prepared by TC 33 "Power
capacitors and their applications" was submitted to the IEC-CENELEC parallel vote and approved by
CENELEC as EN IEC 60358-1:2026.
The following dates are fixed:
• latest date by which the document has to be implemented at national (dop) 2027-02-28
level by publication of an identical national standard or by endorsement
• latest date by which the national standards conflicting with the (dow) 2029-02-28
document have to be withdrawn
This document supersedes EN 60358-1:2012 and all of its amendments and corrigenda (if any).
Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. CENELEC shall not be held responsible for identifying any or all such patent rights.
This document has been prepared under a standardization request addressed to CENELEC by the
European Commission. The Standing Committee of the EFTA States subsequently approves these
requests for its Member States.
Any feedback and questions on this document should be directed to the users’ national committee. A
complete listing of these bodies can be found on the CENELEC website.
Endorsement notice
The text of the International Standard IEC 60358-1:2025 was approved by CENELEC as a European
Standard without any modification.
In the official version, for Bibliography, the following notes have to be added for the standard indicated:
IEC 60060-2 NOTE Approved as EN IEC 60060-2
IEC 60085 NOTE Approved as EN 60085
IEC 60358-2 NOTE Approved as EN 60358-2
IEC 60358-3 NOTE Approved as EN 60358-3
IEC 60358-4 NOTE Approved as EN IEC 60358-4
IEC 60422 NOTE Approved as EN IEC 60422
IEC 61462 NOTE Approved as EN IEC 61462
IEC 61869-5 NOTE Approved as EN 61869-5
IEC 62155 NOTE Approved as EN 62155
IEC 62217:2012 NOTE Approved as EN 62217:2013 (not modified)
IEC 62271-203 NOTE Approved as EN IEC 62271-203
Annex ZA
(normative)
Normative references to international publications
with their corresponding European publications
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments)
applies.
NOTE 1  Where an International Publication has been modified by common modifications, indicated by (mod),
the relevant EN/HD applies.
NOTE 2  Up-to-date information on the latest versions of the European Standards listed in this annex is available
here: www.cencenelec.eu.
Publication Year Title EN/HD Year
IEC 60038 - IEC standard voltages EN 60038 -
IEC 60060-1 - High-voltage test techniques - Part 1: EN IEC 60060-1 -
General terminology and test requirements
IEC 60068-2-11 2021 Environmental testing - Part 2-11: Tests - EN IEC 60068-2-11 2021
Test Ka: Salt mist
IEC 60068-2-17 - Environmental testing - Part 2-17: Tests - EN IEC 60068-2-17 -
Test Q: Sealing
IEC 60071-1 - Insulation co-ordination - Part 1: EN IEC 60071-1 -
Definitions, principles and rules
IEC 60071-2 - Insulation co-ordination - Part 2: EN IEC 60071-2 -
Application guidelines
IEC 60071-11 - Insulation co-ordination - Part 11 - EN IEC 60071-11 -
Definitions, principles and rules for HVDC
system
IEC 60270 - High-voltage test techniques - Charge- EN IEC 60270 -
based measurement of partial discharges
IEC 60296 - Fluids for electrotechnical applications - EN IEC 60296 -
Mineral insulating oils for electrical
equipment
IEC 60376 - Specification of technical grade sulphur EN IEC 60376 -
hexafluoride (SF6) and complementary
gases to be used in its mixtures for use in
electrical equipment
IEC 60480 - Specifications for the re-use of sulphur EN IEC 60480 -
hexafluoride (SF6) and its mixtures in
electrical equipment
IEC 60721 series Classification of environmental conditions - EN 60721 series
Part 1: Environmental parameters and their
severities
IEC/TS 60815-1 2008 Selection and dimensioning of high-voltage - -
insulators intended for use in polluted
conditions - Part 1: Definitions, information
and general principles
IEC/TS 60815-2 2008 Selection and dimensioning of high-voltage - -
insulators intended for use in polluted
conditions - Part 2: Ceramic and glass
insulators for a.c. systems
IEC/TS 60815-3 2008 Selection and dimensioning of high-voltage - -
insulators intended for use in polluted
conditions - Part 3: Polymer insulators for
a.c. systems
IEC 60867 - Insulating liquids - Specifications for EN IEC 60867 -
unused liquids based on synthetic aromatic
hydrocarbons
IEC 61099 - Insulating liquids - Specifications for EN 61099 -
unused synthetic organic esters for
electrical purposes
IEC 62271-4 2022 High-voltage switchgear and controlgear - EN IEC 62271-4 2022
Part 4: Handling procedures for gases for
insulation and/or switching
IEC 62770 - Fluids for electrotechnical applications - EN IEC 62770 -
Unused natural esters for transformers and
similar electrical equipment
IEC 63012 - Insulating liquids - Unused modified or EN IEC 63012 -
blended esters for electrotechnical
applications
ISO 4628-3 - Paints and varnishes - Evaluation of EN ISO 4628-3 -
quantity and size of defects, and of
intensity of uniform changes in appearance
- Part 3: Assessment of degree of rusting
ISO 22479 - Corrosion of metals and alloys - Sulfur EN ISO 22479 -
dioxide test in a humid atmosphere (fixed
gas method)
CISPR/TR 18-2 - Radio interference characteristics of - -
overhead power lines and high-voltage
equipment - Part 2: Methods of
measurement and procedure for
determining limits
