(Main)Fixed Radio Systems; Point-to-point Antennas; Antennas for point-to-point fixed radio systems operating in the frequency band 3 GHz to 60 GHz
General Information
- Abstract
Clarification of antenna XPD categories.
- Status
- Published
- Publication Date
- 30-Nov-2003
- Current Stage
- 6060 - National Implementation/Publication (Adopted Project)
- Start Date
- 01-Dec-2003
- Due Date
- 01-Dec-2003
- Completion Date
- 01-Dec-2003
Overview
SIST EN 300 833 V1.2.1:2003 defines the essential parameters and requirements for antennas used in fixed radio systems operating as point-to-point links in the frequency range from 3 GHz to 60 GHz. Issued by the Slovenski inštitut za standardizacijo (SIST) and identical to EN 300 833, the standard is essential for manufacturers, operators, and regulators involved in high-frequency telecommunications systems. A key focus of this edition is the clarification of antenna cross-polar discrimination (XPD) categories, which are crucial for managing interference and maximizing frequency use in radio networks.
Key Topics
- Frequency Bands: The standard covers sub-bands within 3 GHz to 60 GHz, with detailed classifications for antenna operation across six defined frequency ranges.
- Antenna Types: Specifications apply to single main-beam, linear polarization, and directional antennas, including single polarization, dual polarization, dual band/single polarized, and dual band/dual polarized variants.
- Radiation Pattern Envelope (RPE): Establishes envelope classes (1 to 4) corresponding to interference potential and deployment density, impacting antenna radiation and potential interference.
- Gain Categories: Distinguishes antennas with low and high gain for coordination purposes, ensuring suitability for different radio network capacities.
- Cross-Polar Discrimination (XPD) Categories: Clarifies three categories of XPD performance, including:
- Standard XPD
- High XPD
- High XPD in extended angular regions
- Measurement and Compliance: References standard measurement methods and outlines conformance testing procedures.
Applications
Antennas covered by this standard are integral to a variety of fixed radio communications systems requiring reliable, interference-managed point-to-point transmission, such as:
- Radio Relay Systems: Used for long-distance, high-capacity links between network nodes, particularly where cable infrastructure is impractical.
- Fixed Wireless Backhaul: Essential for mobile network operators connecting cell towers, especially in dense urban and remote rural environments.
- Fixed Satellite Communication Links: Supports ground station interconnects where terrestrial line-of-sight is required.
- Corporate and Critical Infrastructure Networks: Applied in private networks for utilities, transportation, and emergency services needing secure and robust communication channels.
By specifying minimum performance attributes for RPE, XPD, and antenna gain, the standard ensures:
- Efficient spectral management
- Reduced inter- and intra-system interference
- Regulatory compliance for equipment approvals
- Enhanced coexistence of diverse radio services, especially in congested frequency bands
Related Standards
SIST EN 300 833 V1.2.1:2003 refers to and aligns with various international and European standards, enhancing its global relevance:
- EN 301 126-3-1: Fixed Radio Systems - Conformance testing for point-to-point radio equipment.
- IEC 835-2-2: Methods of measurement for digital microwave antenna systems.
- ITU-R F.746-2: International guidelines for radio-frequency channel arrangements in radio-relay systems.
- IEC 169 and IEC 154: Standards for radio-frequency connectors and flanges for waveguides.
Further reference materials include ITU and IEEE guides on antenna definitions, measurements, and radiation patterns, as listed in the bibliography of the standard.
Keywords: fixed radio systems, point-to-point antennas, cross-polar discrimination (XPD), radiation pattern envelope (RPE), frequency band 3 GHz to 60 GHz, antenna gain, radio relay systems, wireless backhaul, interference management, antenna standards, SIST EN 300 833, EN 300 833.
