Energy Performance of Buildings - Controls for heating systems - Part 1: Control equipment for hot water heating systems - Modules M3-5, 6, 7, 8

This European Standard applies to electronic control equipment for heating systems with water as the heating medium and a supply water temperature up to 120 °C.
This control equipment controls the distribution and/or the generation of heat in relation to the outside temperature and time and other reference variables.
This standard covers also controllers that contain an integrated optimum start or an optimum start-stop control function.
Safety requirements on heating systems remain unaffected by this standard.
The dynamic behaviour of the valves and actuators are not covered in this standard.
A multi-distribution and/or multi-generation system needs a coordinated solution to prevent undesired interaction and is not part of this standard.
Table 1 shows the relative position of this standard within the set of EPB standards in the context of the modular structure as set out in prEN ISO 52000 1.
NOTE 1   In prCEN ISO/TR 52000 2 the same table can be found, with, for each module, the numbers of the relevant EPB standards and accompanying technical reports that are published or in preparation.
NOTE 2   The modules represent EPB standards, although one EPB standard may cover more than one module and one module may be covered by more than one EPB standard, for instance a simplified and a detailed method respectively.

Engergieeffizienz von Gebäuden - Mess-, Steuer- und Regeleinrichtungen für Heizungen - Teil 1: Regeleinrichtungen für Warmwasserheizungen - Module M3-5, 6, 7, 8

Diese Norm gilt für elektronische Regeleinrichtungen für Heizungsanlagen mit Wasser als Wärmeträger und einer Vorlauftemperatur bis 120 °C.
Diese Regeleinrichtungen dienen der Steuerung der Wärmeverteilung und/oder -erzeugung in Abhängigkeit von der Außentemperatur, der Zeit und anderen Führungsgrößen.
Diese Norm behandelt auch Regeleinrichtungen mit integrierter Einschalt-Optimierungsfunktion oder Ein /Ausschalt-Optimierungsfunktion.
Sicherheitstechnische Anforderungen an Heizungsanlagen bleiben von dieser Norm unberührt.
Das dynamische Verhalten von Ventilen und Stellgliedern wird in dieser Norm nicht behandelt.
Eine Anlage mit mehreren Verteilkreisen und/oder Erzeugern erfordert eine koordinierte Lösung, um unerwünschte Wechselwirkungen zu vermeiden, und ist nicht Gegenstand dieser Norm.
Tabelle 1 zeigt die relative Position dieser Norm innerhalb des EPB-Normenpaketes im Kontext der in EN ISO 52000 1 dargelegten modularen Struktur.
ANMERKUNG 1   In CEN ISO/TR 52000 2 findet sich die gleiche Tabelle mit den Nummern (für jedes Modul) der jeweiligen EPB-Normen und den dazugehörigen Technischen Berichten, die bereits veröffentlicht wurden oder sich in der Erstellung befinden.
ANMERKUNG 2   Die Module repräsentieren EPB-Normen, auch wenn eine EPB-Norm mehr als ein Modul abdecken kann und ein Modul von mehr als einer EPB-Norm abgedeckt werden kann, zum Beispiel jeweils ein vereinfachtes und ein detailliertes Verfahren.

Performance énergétique des bâtiments - Régulation pour les systèmes de chauffage - Partie 1 : Equipement de régulation pour les systèmes de chauffage à eau chaude - Modules M3-5, 6, 7, 8

La présente Norme européenne s'applique aux dispositifs électroniques de régulation pour les systèmes de chauffage qui utilisent l'eau comme fluide caloporteur, avec une température de l'eau allant jusqu'à 120 °C.
Ces dispositifs de régulation servent à la commande et à la régulation de la distribution et/ou de la production de chaleur en fonction de la température extérieure et du temps, ainsi que d'autres variables de référence.
La présente norme couvre également les régulateurs contenant une fonction intégrée de commande de démarrage optimisé ou de démarrage-arrêt optimisé.
Les exigences de sécurité relatives aux systèmes de chauffage ne sont pas affectées par la présente norme.
Le comportement dynamique des vannes et des actionneurs n'est pas couvert par la présente norme.
Un système multi-distribution et/ou multi-production nécessite une solution coordonnée pour empêcher toute interaction indésirable, mais un tel système ne relève pas du domaine d'application de la présente norme.
Le tableau 1 présente la position de cette norme dans l’ensemble des normes PEB et dans le contexte de la structure modulaire comme décrit dans EN ISO 52000-1.
NOTE 1   Le même tableau se trouve dans CEN ISO/TR 52000-2 avec, pour chaque module, le nombre des normes PEB et les rapports techniques (TR) qui les accompagnent, publiés ou en préparation.
NOTE 2   Les modules représentent les normes PEB, bien qu’une norme peut recouvrir plus qu’un module et qu’un module peut être recouvert par plus qu’une norme PEB, comme par exemple une méthode simplifiée et une détaillée.

Energijske lastnosti stavb - Naprave za regulacijo sistemov za ogrevanje - 1. del: Naprave za regulacijo toplovodnih sistemov za ogrevanje - Moduli M3-5, 6, 7, 8

Ta standard se uporablja za elektronske naprave za regulacijo delovanja grelnih sistemov, pri katerih je grelni medij voda, ki dosega temperaturo do 120 °C. Ta naprava za regulacijo delovanja nadzira in ureja razporeditev in/ali proizvodnjo toplote glede na zunanjo temperaturo in čas ter druge referenčne spremenljivke. Ta standard zajema tudi regulacijske naprave z vgrajeno nadzorno funkcijo za optimalni začetek ali optimalni začetek/konec. Ta standard ne vpliva na varnostne zahteve za grelne sisteme. Dinamično obnašanje ventilov in sprožilnikov ni zajeto v tem standardu. Večdistribucijski in/ali večproizvodni sistem potrebuje usklajeno rešitev, da se preprečijo neželeni medsebojni vplivi, in ni del tega standarda.
