Child care articles - Wheeled child conveyances - Safety requirements and test methods
Articles de puériculture - Voitures d'enfant - Exigences de sécurité et méthodes d'essai
Artikel für Säuglinge und Kleinkinder - Transportmittel auf Rädern für Kinder - Sicherheitstechnische Anforderungen und Prüfungen This European Standard was approved by CEN on 16 December 2011.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2012 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 1888:2012: ESIST EN 1888:2012

Rationales . 66A.1 General . 66A.2 Chemical hazards (see Clause 6) . 66A.3 Thermal hazards (see Clause 7) . 66A.4 Mechanical hazards (see Clause 8) . 66A.4.1 General . 66A.4.2 Protective function (see 8.1) . 66A.4.3 Entrapment hazards (see 8.2) . 66A.4.4 Hazards from moving parts (see 8.3) . 67A.5 Entanglement hazards (see 8.4) . 67A.6 Choking and ingestion hazards (see 8.5) . 67A.7 Suffocation hazards (see 8.6) . 67A.8 Hazardous edges and protrusions (see 8.7) . 67A.9 Parking and braking devices (see 8.8) . 68A.10 Stability (see 8.9) . 68A.11 Structural integrity (see 8.10) . 68Annex B (informative)
Examples of articulated arms to maintain the vehicle on the rig for the irregular surface test . 69Annex C (informative)
Guideline for the application of 8.3.3.1.1.3 "Unintentional release of locking mechanism(s)" . 70C.1 Relevant definitions . 70C.2 Guidelines for the application of 8.3.3.1.1.3 "Unintentional release of locking mechanism(s)" . 70C.2.1 General . 70SIST EN 1888:2012

A-deviation . 74Bibliography . 75 SIST EN 1888:2012

3.14 junction line intersection of the seat and the backrest 3.15 folding system assembly of moving parts which enables the vehicle to be changed from an erected position to a folded position and vice versa under the control of the carer 3.16 locking device mechanical component that maintains part(s) of the vehicle erected in the position of use (e.g. latch(es), hooks, over centre lock.) which could be deactivated or activated by action(s) on the operating device 3.17 operating device part of the locking mechanism(s) designed to be activated by the carer through one or several positive action(s) 3.18 locking mechanism assembly of components consisting of one or more locking device(s) and one or more operating device(s) SIST EN 1888:2012

Key 1 origin from which the protected volume has been defined (mid-point of the junction line, on the uncompressed upper surface of the seat unit) 2 seat 3 back rest 4 leg rest Figure 1 — Protected volume for seat units The space located behind the backrest is excluded from the protected volume. Where a vehicle is suitable for two or more children the space located behind the backrest shall be considered if it enters another protected volume. The space underneath the seat and underneath the leg rest is excluded from the protected volume, except for a 50 mm wide band measured from the outermost edge of the seat/leg rest sides where the seat/leg rest is not fitted with lateral protections of a height greater than 50 mm (textile or any rigid component), (see Figure 2). SIST EN 1888:2012

a) Side view b) Bottom view Key 1 space to be checked 2 space not to be checked 3 leg rest 4 seat 5 backrest Figure 2 — Effect of lateral protection on the determination of the protected volume 4.5.2 Protected volume of pram bodies having a length greater than 800 mm The protected volume of pram bodies having a length greater than 800 mm shall be determined in accordance with Figure 3. The 550 mm height shall be measured in accordance with 8.1.2.2. The surface underneath the pram body is excluded from the protected volume. SIST EN 1888:2012

Figure 3 — Protected volume for pram bodies having a length greater than 800 mm 4.5.3 Protected volume for pram bodies having a maximum internal length of 800 mm and car seats For vehicles designed only for children under 6 months of age, pram bodies with a maximum internal length of 800 mm and for car seats, the protected volume is considered to be the inner upper surface that supports the child and the inner surface of the sides and ends of the pram body. 4.6 Determination of the junction line The junction line shall be determined as the intersection between the seat and the backrest as shown on Figure 4.
Key LL junction line Figure 4 — Junction line When the seat unit is in the form of a hammock, then a theoretical junction line, “LL”, is determined as shown in Figure 5. SIST EN 1888:2012

Key LL junction line CL vertical projection of C on the hammock Figure 5 — Junction line for seat unit in form of a hammock NOTE The junction line may vary when the backrest is adjusted to different positions. 5 Test equipment 5.1 Test masses 5.1.1 General Unless otherwise specified, the test masses shall be those given in 5.1.2 to 5.1.9. Any damage to fabric which may occur as a result of abrasion by the test masses during tests shall be ignored. Damage can be minimized by using a convenient means of protection of negligible mass. Where damage is not caused by abrasion by the test masses it constitutes a structural failure. 5.1.2 Test mass A Test mass A is a rigid cylinder (160 ± 5) mm in diameter and (300 ± 5) mm in height, having a mass of (9 + 0,01/0) kg and with its centre of gravity in the centre of the cylinder. All edges shall have a radius of (5 ± 1) mm. Two anchorage points shall be provided, positioned (150 ± 2,5) mm from the base and at 180° to each other around the circumference as shown in Figure 6. SIST EN 1888:2012

Key 1 radius: (5 ± 1) mm 2 two anchorage points Figure 6 — Test mass A 5.1.3 Test mass B Test mass B is a rigid cylinder (200 ± 5) mm in diameter and (300 ± 5) mm in height, having a mass of (15 + 0,01/0) kg and with its centre of gravity in the centre of the cylinder. All edges shall have a radius of (5 ± 1) mm. Two anchorage points shall be provided, positioned (150 ± 2,5) mm from the base and at 180° to each other around the circumference (see Figure 7). Dimensions in millimetres
Key 1 radius: (5 ± 1) mm 2 two anchorage points Figure 7 — Test mass B SIST EN 1888:2012

Key 1 hinge line Figure 8 — Test mass C SIST EN 1888:2012

Tolerances dimensions ± 2 mm angles ± 2°where shown, corner radii shall be (10 ± 1) mm Figure 9 — Test mass D SIST EN 1888:2012

Tolerances dimensions ± 2 mm angles ± 2 °where shown, corner radii shall be (10 ± 1) mm Figure 10 — Test mass D0 SIST EN 1888:2012

Key 1 radius (5 ± 1) mm 2 anchorage points Figure 11 — Test mass F SIST EN 1888:2012

Figure 12 — Test mass G The distance between the two identical parts of test mass G shall be adjusted in accordance with the shape and dimensions of the platform that is tested. A rigid bar of negligible mass shall be used to maintain the test mass along the platform and both parts shall be maintained apart from each other by any connecting means of negligible mass. SIST EN 1888:2012

Key 1 hemispherical end 2 scribed line around circumference 3 Ø 5 mm 7 mm and 12 mm Figure 13 — Probes with hemispherical end 5.2.1.2 Conical probe for mesh Probe for assessing mesh made from plastics or other hard, smooth material as shown in Figure 14 which shall be capable of being mounted on a force measuring device, so that the conical end can be presented to the opening being assessed. Dimensions in millimetres
Figure 14 — Conical probe for mesh The tolerance on the radius is ± 0,2 mm. SIST EN 1888:2012

Figure 15 — Conical probes 5.2.2 Hip probe The hip probe shall be made from plastics or other hard, smooth material with the dimensions given in Figure 16.
Dimensions in millimetres
Key H handgrip tolerances on dimensions: - 65 (0 / –0,5) mm - 105 (0 /–0,5) mm all other dimensions shall be ± 1 mm. Figure 16 — Hip probe SIST EN 1888:2012

Key 1 handgrip Figure 17 — Large head probe 5.3 Angle measuring device A 9 kg articulated steel device used to measure the angle between the seat and the backrest (see Figure 18). SIST EN 1888:2012

Key 1 part to be placed onto the seat surface made of steel 2 part to be placed onto the backrest surface made of steel 3 hinge pin made of steel E mass: (4495 ± 50) g F mass: (4501 ± 50) g G mass of hinge axle: (17 ± 0,5) g, length: 79,5 mm. total mass tolerance: (9 ± 0,1) kg dimensions tolerance: ± 2 mm All edges shall be chamfered. Figure 18 — Angle measuring device SIST EN 1888:2012

Key 1 hole Ø 3 mm 2 steel cable Ø 1,5 mm 3 tube Ø 25 mm 4 tube Ø 25 mm 5 steel cable Ø1,5 mm 6 cable ends cycle type 7 total length = 13 tubes length of each tube: 60 mm Figure 19 — Hinged board SIST EN 1888:2012

Figure 20 — Small parts cylinder 5.7 Bite tester The bite tester, see Figure 21, consists of two sets of teeth, see Figure 22, made from H13 high chrome tool steel or equivalent and hardened to 45-50 Rockwell C. There are two teeth at the top and two at the bottom of the bite tester, positioned so that the vertical centre line of one pair of teeth is (1 ± 0,1) mm in front of the centre line of the other set of teeth. In the fully closed position, the teeth shall overlap each other by (1 ± 0,1) mm. The outer most corners of the teeth shall have a radius of (0,3 ± 0,1) mm. The teeth shall be mounted so as to pivot about a point (50 ± 1) mm from the rear most pair of teeth and positioned so that when closed the centre lines of the two pairs of teeth are parallel to each other. The bite tester shall be equipped with a stop to prevent the distance between the teeth from exceeding (28 ± 1) mm when fully opened. The closing force of the teeth shall be set at (50 ± 5) N.
The bite tester shall be provided with a guide to prevent items entering further into the fully opened jaws by more than (17 ± 1) mm. The bite tester shall be equipped with a means whereby a force of (50 ± 5) N may be applied along its centre line in a direction tending to pull the teeth off the sample. SIST EN 1888:2012

Key 1 position of guide
2 pivot point
Figure 21 — Bite tester Dimensions in millimetres
Figure 22 — Test teeth SIST EN 1888:2012

5.10 Irregular surface test equipment 5.10.1 Obstacles The surface of the irregular surface test equipment shall comprise two types of obstacles: Type A and Type B as shown in Figures 23 and 24. These obstacles shall be mounted on a conveyor system as shown in Figure 25 so that the wheels on each side of the vehicle are lifted alternately. The conveyor system shall run at a speed of (5 ± 0,1) km/h. Dimensions in millimetres
Figure 23 — Type "A" obstacle for the irregular surface test Dimensions in millimetres
Key 1 direction of travel Figure 24 — Type "B" obstacle for the irregular surface test SIST EN 1888:2012

Key 1 front wheels 2 back wheels 3 centre line 4 length of 1 cycle 5 direction of the travel of obstacles Figure 25 — Arrangement for the irregular surface test 5.10.2 Articulating arms (see Annex B) The test apparatus comprises two independent articulating arms capable of moving independently of each other in the vertical plane. The test apparatus shall allow the articulating arms to be adjustable in height and across the width of the irregular surface test equipment to accommodate different types and sizes of vehicle. The articulating arms shall pivot around their fixing point. When in the horizontal position, each arm shall exert a vertical force on the handles of (20 ± 1) N. SIST EN 1888:2012

Where a surface is coated with a multi-layer of paint or similar coating, the test sample shall not include the base material. 7 Thermal hazards (see A.3) Fabrics shall not produce a surface flash when applying a flame as described in EN 1103. A separate sample may be used for these tests. 8 Mechanical hazards (see A.4) 8.1 Protective function (see A.4.2) 8.1.1 Suitability of vehicle
8.1.1.1 Requirements
8.1.1.1.1 Vehicles intended for use from birth Vehicles intended for children from birth shall comprise one of the following: a) a pram body conforming to the requirements of 8.1.2 ; or b) a seat unit where the angle between the backrest and the seat (angle "1" in Figure 26) is capable of adjustment to an angle of 150° or more measured in accordance with 8.1.1.2.1 and conforming to 8.1.2: any parts, whose function is essential for complying to 8.1.2, shall not allow the test ball to fall from the seat unit when tested in accordance with 8.1.1.2.2. In this configuration the restraint system shall be SIST EN 1888:2012

d) any "car seat" suitable from birth conforming to ECE 44. 8.1.1.1.2 Vehicles intended for use from 6 months of age Car seats which comply with ECE 44 are exempt from this requirement. Vehicles intended for children from 6 months of age shall have a restraint system complying with the relevant requirements of 8.1.3. Seat units intended to be used from 6 months of age shall be marked with the warning in 10.2.5. The warning shall be visible during folding, unfolding or adjustment of the vehicle. 8.1.1.1.3 Seat units Car seats which comply with ECE 44 are exempt from these requirements. When measured in accordance with 8.1.1.2.1:  the angle (1) between the seat and the backrest (see Figure 26) shall not be less than 95°; and  the angle (2) between the seat and the horizontal (see Figure 26) shall not be less than 0°; and
 the angle (3) between the backrest and the horizontal (see Figure 26) shall not be less than 0°. NOTE Angles below the horizontal line are considered to be less than 0°. The length of the backrest shall not be less than 380 mm. When tested in accordance with 8.1.1.2.1 the top of the backrest of the seat unit shall be equal to or higher than the top of part 2 of the angle measuring device. Car seats which comply with ECE 44 are exempt from these requirements. SIST EN 1888:2012

Key 1 angle between the seat and the backrest 2 angle between the seat and the horizontal 3 angle between backrest and the horizontal 4 seat unit 5 angle measuring device 6 horizontal Figure 26 — Measurement of angle of backrest 8.1.1.2 Test methods 8.1.1.2.1 Measurement of angle and length of the backrest Adjust the backrest of the seat unit to its most upright position. Any removable head cushion shall be removed before performing the measurements NOTE Any component that may impair the correct positioning of part 1 of the angle measuring device (crotchstrap, padded parts, buckle etc.) should be positioned such as to ensure part 1 of the device is correctly placed onto the seat. Place the angle measuring device (see 5.3) on the seat unit with part 1 against the seat and with part 2 (Figure 18) against the backrest as shown in Figure 26. Raise the whole device for at least 50 mm from the seat with part 2 (Figure 18) maintaining complete contact with the backrest. With the device in this position fold up part 1 to its maximum reach. Then lower the whole device as far as possible by its own weight, with part 2 (Figure 18) maintaining complete contact with the backrest. Then slowly unfold part 1 (Figure 18
...
