SIST EN 302 288-2 V1.6.1:2012

Harmonized European Standard
Electromagnetic compatibility
and Radio spectrum Matters (ERM);
Short Range Devices;
Road Transport and Traffic Telematics (RTTT);
Short range radar equipment operating in the 24 GHz range;
Part 2: Harmonized EN covering the essential requirements of
article 3.2 of the R&TTE Directive

2 ETSI EN 302 288-2 V1.6.1 (2012-03)

Reference
REN/ERM-TGSRR-056-2
Keywords
radar, radio, regulation, RTTT, SRD, testing
ETSI
650 Route des Lucioles
F-06921 Sophia Antipolis Cedex - FRANCE

Tel.: +33 4 92 94 42 00  Fax: +33 4 93 65 47 16

Siret N° 348 623 562 00017 - NAF 742 C
Association à but non lucratif enregistrée à la
Sous-Préfecture de Grasse (06) N° 7803/88

Important notice
Individual copies of the present document can be downloaded from:
http://www.etsi.org
The present document may be made available in more than one electronic version or in print. In any case of existing or
perceived difference in contents between such versions, the reference version is the Portable Document Format (PDF).
In case of dispute, the reference shall be the printing on ETSI printers of the PDF version kept on a specific network drive
within ETSI Secretariat.
Users of the present document should be aware that the document may be subject to revision or change of status.
Information on the current status of this and other ETSI documents is available at
http://portal.etsi.org/tb/status/status.asp
If you find errors in the present document, please send your comment to one of the following services:
http://portal.etsi.org/chaircor/ETSI_support.asp
Copyright Notification
No part may be reproduced except as authorized by written permission.
The copyright and the foregoing restriction extend to reproduction in all media.

© European Telecommunications Standards Institute 2012.
All rights reserved.
TM TM TM
DECT , PLUGTESTS , UMTS and the ETSI logo are Trade Marks of ETSI registered for the benefit of its Members.
TM
3GPP and LTE™ are Trade Marks of ETSI registered for the benefit of its Members and
of the 3GPP Organizational Partners.
GSM® and the GSM logo are Trade Marks registered and owned by the GSM Association.
ETSI
3 ETSI EN 302 288-2 V1.6.1 (2012-03)
Contents
Intellectual Property Rights . 5
Foreword . 5
Introduction . 5
1 Scope . 6
2 References . 6
2.1 Normative references . 6
2.2 Informative references . 7
3 Definitions, symbols and abbreviations . 7
3.1 Definitions . 7
3.2 Symbols . 7
3.3 Abbreviations . 7
4 Technical requirements specifications . 8
4.1 Environmental conditions . 8
4.1.1 Environmental profile . 8
4.2 Conformance requirements . 8
4.2.1 Transmitter requirements . 8
4.2.1.1 Limits for transmitters in the range from 22 GHz to 26,65 GHz for type A and B . 8
4.2.1.1.1 Permitted range of operating frequencies for type A . 8
4.2.1.1.2 Permitted range of operating frequencies for type B . 8
4.2.1.1.3 Maximum radiated average power density (e.i.r.p.) for type A . 8
4.2.1.1.4 Maximum radiated average power density (e.i.r.p.) for type B . 8
4.2.1.1.5 Maximum radiated peak power density (e.i.r.p.) for type A . 8
4.2.1.1.6 Maximum radiated peak power density (e.i.r.p.) for type B . 8
4.2.1.2 Limits for transmitters in the range from 24,05 GHz to 24,25 GHz . 8
4.2.1.2.1 Permitted range of operating frequencies . 8
4.2.1.2.2 Limit for transmitted peak power (e.i.r.p.) in the 24,05 GHz to 24,25 GHz SRD band . 9
4.2.1.3 Vertical plane emission limits in the range from 23,6 GHz to 24,0 GHz . 9
4.2.1.4 Emission limits in the range from 24,05 GHz to 26,65 GHz . 9
4.2.1.5 Transmitter emissions in the non-operating-frequency range . 9
4.2.2 Receiver requirements . 9
4.2.2.1 Receiver spurious emissions . 9
4.2.3 Installation requirements . 9
5 Testing for compliance with technical requirements . 9
5.1 Environmental conditions for testing . 9
5.2 Essential radio test suites . 9
5.2.1 Transmitter test suites . 9
5.2.1.1 Transmitters operating in the 22 GHz to 26,65 GHz band . 9
5.2.1.1.1 Permitted range of operating frequencies . 9
5.2.1.1.2 Maximum radiated average power density (e.i.r.p.) . 9
5.2.1.1.3 Maximum radiated peak power density (e.i.r.p.) . 10
5.2.1.2 Transmitters operating in the 24,050 GHz to 24,250 GHz band . 10
5.2.1.2.1 Permitted range of operating frequencies . 10
5.2.1.2.2 Equivalent isotropically radiated power (e.i.r.p.) . 10
5.2.1.3 Vertical plane transmitter emissions . 10
5.2.1.4 Transmitter emissions in the Radiated emissions in the non-operating-frequency range . 10
5.2.2 Receiver test suites. 10
5.2.2.1 Receiver spurious emissions . 10
5.2.3 Installation requirements . 10
5.3 Interpretation of results and measurement uncertainty . 10
Annex A (normative): HS Requirements and conformance Test specifications Table (HS-
RTT) . 12
ETSI
4 ETSI EN 302 288-2 V1.6.1 (2012-03)
Annex B (informative): Bibliography . 14
History . 15

ETSI
5 ETSI EN 302 288-2 V1.6.1 (2012-03)
Intellectual Property Rights
IPRs essential or potentially essential to the present document may have been declared to ETSI. The information
pertaining to these essential IPRs, if any, is publicly available for ETSI members and non-members, and can be found
in ETSI SR 000 314: "Intellectual Property Rights (IPRs); Essential, or potentially Essential, IPRs notified to ETSI in
respect of ETSI standards", which is available from the ETSI Secretariat. Latest updates are available on the ETSI Web
server (http://ipr.etsi.org).
Pursuant to the ETSI IPR Policy, no investigation, including IPR searches, has been carried out by ETSI. No guarantee
can be given as to the existence of other IPRs not referenced in ETSI SR 000 314 (or the updates on the ETSI Web
server) which are, or may be, or may become, essential to the present document.
Foreword
This Harmonized European Standard (EN) has been produced by ETSI Technical Committee Electromagnetic
compatibility and Radio spectrum Matters (ERM).
The present document has been produced by ETSI in response to a mandate from the European Commission issued
under Directive 98/34/EC [i.1] as amended by Directive 98/48/EC [i.9].
The title and reference to the present document are intended to be included in the publication in the Official Journal of
the European Union of titles and references of Harmonized Standard under the Directive 1999/5/EC [i.2].
See article 5.1 of Directive 1999/5/EC [i.2] for information on presumption of conformity and Harmonised Standards or
parts thereof the references of which have been published in the Official Journal of the European Union.
The requirements relevant to Directive 1999/5/EC [i.2] are summarised in annex A.
The present document is part 2 of a multi-part deliverable covering Electromagnetic compatibility and Radio spectrum
Matters (ERM); Short Range Devices, Road Transport and Traffic Telematics (RTTT); Short range radar equipment
operating in the 24 GHz range, as identified below:
Part 1: "Technical requirements and methods of measurement";
Part 2: "Harmonized EN covering the essential requirements of article 3.2 of the R&TTE Directive".

National transposition dates
Date of adoption of this EN: 19 March 2012
Date of latest announcement of this EN (doa): 30 June 2012
Date of latest publication of new National Standard
or endorsement of this EN (dop/e): 31 December 2012
Date of withdrawal of any conflicting National Standard (dow): 31 December 2013

Introduction
The present document is part of a set of standards developed by ETSI and is designed to fit in a modular structure to
cover all radio and telecommunications terminal equipment within the scope of the R&TTE Directive [i.2]. The
modular structure is shown in EG 201 399 [i.3].
The communications terminal equipment within the scope of the R&TTE Directive [i.2]. The modular structure is
shown in EG 201 399 [i.3].
ETSI
6 ETSI EN 302 288-2 V1.6.1 (2012-03)
1 Scope
The present document applies to Short Range Devices (SRDs) in Road Transport and Traffic Telematics (RTTT)
systems as described in the scope of EN 302 288-1 [1]:
• with an integral antenna;
• for ultra low power motion and distance monitoring radars for mobile applications only;
• the operating frequency range for intentional UWB emissions has been determined for the range of
th st
22,000 GHz to 26,65 GHz until 30 June 2013 and from 24,25 GHz to 26,65 GHz until 1 January 2018.
However, the date of 1 January 2018 will be extended by 4 years for automotive short-range radar equipment
mounted on motor vehicles for which a type approval application has been submitted pursuant to Article 6(6)
st
of Directive 2007/46/EC [i.8] and has been granted before 1 January 2018.
The applicability of the present document covers only the 24 GHz Short Range Radar (SRR) for road vehicles. The
present document does not necessarily include all the characteristics which may be required by a user, nor does it
necessarily represent the optimum performance achievable.
NOTE: Member States of the European Union are requested to prohibit the taking into service of equipment
covered by the present document after a date defined in Commission Decision 2005/50/EC [i.7].
The present document covers transmitters intended to operate in a temporary frequency designation under the EU
Commission decision on 24 GHz SRR EC 2005/50/EC [i.7] and the amendment as presented in RSCOM11-21 [i.7].
The present document is intended to cover the provisions of Directive 1999/5/EC (R&TTE Directive) [i.2], article 3.2,
which states that "… radio equipment shall be so constructed that it effectively uses the spectrum allocated to
terrestrial/space radio communications and orbital resources so as to avoid harmful interference".
The present document responds to the EC mandate M/329 [i.6] for Harmonized Standards covering UltraWide
Band (UWB) applications.
