Overview
SIST EN 300 645 V1.2.1:2003 is a European standard that provides an object-oriented information model for the management of Synchronous Digital Hierarchy (SDH) radio relay equipment. Developed within the framework of the Telecommunications Management Network (TMN), this standard specifically addresses radio relay network elements and their management through Q interfaces. The purpose is to harmonize with ITU-T Recommendation G.774.08, ensuring compatibility and alignment with internationally recognized guidelines.
By adopting this standard, organizations benefit from consistent structuring of management information, improved interoperability, and a solid base for developing management solutions for SDH radio relay networks.
Key Topics
SDH Radio Relay Management
The standard sets forth an information model designed for SDH radio relay equipment, covering:
- Object classes that represent network elements, functions, and their relationships
- Packages and parameters for encapsulating management-related data and operational features
- Attributes representing configuration options and status indicators relevant to SDH radio relays
- Actions that can be invoked for operational management, such as exercise testing and status change requests
- Name bindings, which define the associations between managed objects
Object-Oriented Modelling
The approach uses object-oriented principles, providing:
- Modular, reusable object definitions
- Hierarchical relationships to streamline network management
Interface Focus
The model is intended for use at the Q interface between element managers and network elements, focusing on information exchange and element visibility within the equipment domain. Protocols, application contexts, and network-level processes are outside its current scope.
Model Alignment
A key value is alignment with ITU-T G.774.08, supporting global compatibility and improved network integration.
Applications
Practical Uses in Telecommunications Networks
- Network Operations: Enables effective monitoring and configuration of radio relay equipment used in SDH-based transmission systems.
- Element Management: Streamlines the management of discrete network elements by standardizing their representation, supporting performance monitoring, fault management, and status reporting.
- Radio Relay Systems: Supports interoperability between management systems and SDH radio relay hardware from different vendors, facilitating multi-vendor environments.
- System Integration: Assists in integrating new radio relay equipment into existing TMN frameworks by providing a consistent management information model.
- Vendor Development: Assists equipment manufacturers in designing products that can be efficiently managed using industry-standard models.
Related Standards
Organizations implementing SIST EN 300 645 V1.2.1:2003 may also reference these related standards and recommendations for comprehensive TMN solutions:
- ITU-T Recommendation G.774 - SDH management information model for network element view
- ETS 300 304 - SDH network element information model
- ITU-T Recommendations:
- G.773 (Protocol suites for Q-interfaces)
- G.781, G.782, G.783, G.784, G.803 (SDH equipment and network architecture)
- G.831 (Management capabilities for SDH networks)
- M.3010, M.3100 (TMN principles and generic network information models)
- X.701, X.710, X.711, X.720, X.721, X.722, X.730, X.731, X.733, X.734, X.735 (OSI management and modeling methodologies)
- ITU-R Recommendation 750 - Architectural aspects of radio-relay systems for SDH networks
Implementing these standards together optimizes the management, reliability, and future scalability of telecommunications networks using SDH radio relay equipment.
Keywords: SDH, telecommunications management network, radio relay equipment, information model, Q interface, network management, object-oriented model, TMN, transmission systems, interoperability.
