ISO 3191:1998
(Main)Aerospace — Nuts, anchor, self-locking, fixed, single lug, reduced series, with counterbore, with MJ threads, classifications: 1 100 MPa (at ambient temperature)/235 degrees C, 1 100 MPa (at ambient temperature)/315 degrees C and 1 100 MPa (at ambient temperature)/425 degrees C — Dimensions
Aerospace — Nuts, anchor, self-locking, fixed, single lug, reduced series, with counterbore, with MJ threads, classifications: 1 100 MPa (at ambient temperature)/235 degrees C, 1 100 MPa (at ambient temperature)/315 degrees C and 1 100 MPa (at ambient temperature)/425 degrees C — Dimensions
This International Standard specifies the dimensions of self-locking, fixed, single lug anchor nuts, reduced series, with counterbore, with MJ threads, for classifications: 1 100 MPa1)/235 °C2), 1 100 MPa1)/315 °C2) and 1 100 MPa1)/425 °C2). This International Standard is only applicable for the compilation of aerospace product standards.
Aéronautique et espace — Écrous à river, à freinage interne, fixes, simple patte, série réduite, avec chambrage, à filetage MJ, classifications: 1 100 MPa (à température ambiante )/235 degrés C, 1 100 MPa (à température ambiante) /315 degrés C et 1 100 MPa (à température ambiante )/425 degrés C — Dimensions
La présente Norme internationale prescrit les dimensions des écrous à river, à freinage interne, fixes, simple patte, série réduite, avec chambrage, à filetage MJ, de classifications: 1 100 MPa1)/235 °C2), 1 100 MPa1)/315 °C2) et 1 100 MPa1)/425 °C2). La présente Norme internationale est applicable uniquement à l'élaboration de normes de produit destinées aux constructions aérospatiales.
General Information
- Status
- Published
- Publication Date
- 02-Dec-1998
- Technical Committee
- ISO/TC 20/SC 4 - Aerospace fastener systems
- Drafting Committee
- ISO/TC 20/SC 4 - Aerospace fastener systems
- Current Stage
- 9093 - International Standard confirmed
- Start Date
- 19-Oct-2021
- Completion Date
- 14-Feb-2026
Relations
- Consolidated By
ISO 14589:2000 - Blind rivets — Mechanical testing - Effective Date
- 06-Jun-2022
- Effective Date
- 15-Apr-2008
Overview
ISO 3191:1998 is an internationally recognized standard developed by the International Organization for Standardization (ISO) focused on aerospace hardware. Specifically, the standard defines the dimensions for self-locking, fixed, single lug anchor nuts of reduced series, equipped with counterbores and MJ threads. The classification covers nuts capable of withstanding a minimum tensile stress of 1,100 MPa at ambient temperature, and operational temperatures up to 235°C, 315°C, and 425°C. This specification is foundational in the development and compilation of aerospace product standards, ensuring interoperability and safety in critical fastening applications.
Key Topics
- Self-locking Anchor Nuts: These nuts prevent loosening due to vibration, which is essential in aerospace environments where component integrity is critical.
- Single Lug and Reduced Series: The single lug design simplifies installation in confined aircraft structures, while the reduced series optimizes weight without compromising strength.
- Counterbore and MJ Threads: The presence of a counterbore and usage of metric MJ thread profiles ensures compatibility with standardized aerospace bolts and improved load distribution.
- Classifications by Temperature: ISO 3191:1998 delineates requirements for anchor nuts based on their mechanical strength (1,100 MPa) and their ability to perform reliably at three specified maximum temperatures (235°C, 315°C, and 425°C).
- Dimensional Specification: The standard prescribes all required measurements, tolerances, and form factors, including the application of surface coatings and the maintenance of tolerances post-coating.
Applications
ISO 3191:1998 is vital in the design and production of aircraft and spacecraft fasteners, being used in:
- Aircraft structural assemblies: Anchor nuts specified by this standard are used for creating secure, vibration-resistant joints in airframes and critical sub-assemblies.
- Aerospace system installations: The self-locking and fixed nature of the nuts make them ideal for attaching equipment, brackets, and other components in environments subject to mechanical stress and high temperatures.
- Maintenance and repair: Standardized dimensions allow for straightforward replacement and maintenance, streamlining procurement and enhancing supply chain reliability.
- High-temperature applications: The classification system enables engineers to select suitable hardware based on expected temperature exposure, supporting safety and compliance in high-performance aircraft.
Related Standards
To ensure full compatibility and performance, ISO 3191:1998 references several other essential aerospace fastener standards:
- ISO 5855-2: Aerospace - MJ threads - Part 2: Limit dimensions for bolts and nuts. Defines thread dimensions for compatible hardware.
- ISO 5858: Aerospace - Self-locking nuts with maximum operating temperature ≤ 425°C - Procurement specification. Specifies broader requirements for self-locking nuts.
- ISO 8788: Aerospace - Fasteners - Tolerances of form and position for nuts. Details manufacturing tolerances for form and positioning.
Together, these standards form the backbone of reliable aerospace fastening systems, supporting performance, safety, and global interoperability within the aviation and space industries.
Keywords: ISO 3191:1998, aerospace standard, anchor nuts, self-locking nuts, single lug, MJ threads, high temperature fasteners, reduced series nut, aircraft fastener standard, dimensions for aerospace nuts, aerospace hardware specification.
