EN 60749-26:2014

SLOVENSKI STANDARD
01-julij-2014
1DGRPHãþD
SIST EN 60749-26:2007
3ROSUHYRGQLãNLHOHPHQWL0HKDQVNHLQNOLPDWVNHSUHVNXVQHPHWRGHGHO
3UHVNXãDQMHREþXWOMLYRVWLQDHOHNWURVWDWLþQHL]SUD]QLWYH(6'0RGHOþORYHãNHJD
WHOHVD+%0
Semiconductor devices - Mechanical and climatic test methods -- Part 26: Electrostatic
discharge (ESD) sensitivity testing - Human body model (HBM)
Halbleiterbauelemente – Mechanische und klimatische Prüfverfahren -- Teil 26: Prüfung
der Empfindlichkeit gegen elektrostatische Entladungen (ESD) - Human Body Model
(HBM)
Dispositifs à semiconducteurs - Méthodes d'essais mécaniques et climatiques -- Partie
26: Essai de sensibilité aux décharges électrostatiques (DES) - Modèle du corps humain
(HBM)
Ta slovenski standard je istoveten z: EN 60749-26:2014
ICS:
31.080.01 Polprevodniški elementi Semiconductor devices in
(naprave) na splošno general
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

EUROPEAN STANDARD EN 60749-26

NORME EUROPÉENNE
EUROPÄISCHE NORM
May 2014
ICS 31.080.01 Supersedes EN 60749-26:2006
English Version
Semiconductor devices - Mechanical and climatic test methods -
Part 26: Electrostatic discharge (ESD) sensitivity testing -
Human body model (HBM)
(IEC 60749-26:2013)
Dispositifs à semiconducteurs - Méthodes d'essais Halbleiterbauelemente - Mechanische und klimatische
mécaniques et climatiques - Partie 26: Essai de sensibilité Prüfverfahren - Teil 26: Prüfung der Empfindlichkeit gegen
aux décharges électrostatiques (DES) - Modèle du corps elektrostatische Entladungen (ESD) - Human Body Model
humain (HBM) (HBM)
(CEI 60749-26:2013) (IEC 60749-26:2013)
This European Standard was approved by CENELEC on 2014-04-14. CENELEC members are bound to comply with the CEN/CENELEC
Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration.
Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC
Management Centre or to any CENELEC member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation
under the responsibility of a CENELEC member into its own language and notified to the CEN-CENELEC Management Centre has the
same status as the official versions.
CENELEC members are the national electrotechnical committees of Austria, Belgium, Bulgaria, Croatia, Cyprus, the Czech Republic,
Denmark, Estonia, Finland, Former Yugoslav Republic of Macedonia, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia,
Lithuania, Luxembourg, Malta, the Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland,
Turkey and the United Kingdom.

European Committee for Electrotechnical Standardization
Comité Européen de Normalisation Electrotechnique
Europäisches Komitee für Elektrotechnische Normung
CEN-CENELEC Management Centre: Avenue Marnix 17, B-1000 Brussels
© 2014 CENELEC All rights of exploitation in any form and by any means reserved worldwide for CENELEC Members.
Ref. No. EN 60749-26:2014 E
Foreword
This document (EN 60749-26:2014) consists of the text of IEC 60749-26:2013 prepared by IEC/TC 47
"Semiconductor devices", in collaboration with Technical Committee 101.

The following dates are fixed:
(dop) 2015-04-14
• latest date by which the document has to be
implemented at national level by
publication of an identical national
standard or by endorsement
(dow) 2017-04-14
• latest date by which the national
standards conflicting with the
document have to be withdrawn
This document supersedes EN 60749-26:2006.

EN 60749-26:2006:
a) descriptions of oscilloscope and current transducers have been refined and updated;
b) the HBM circuit schematic and description have been improved;
c) the description of stress test equipment qualification and verification has been completely re-
written;
d) qualification and verification of test fixture boards has been revised;
e) a new section on the determination of ringing in the current waveform has been added;
f) some alternate pin combinations have been included;
g) allowance for non-supply pins to stress to a limited number of supply pin groups (associated non-
supply pins) and allowance for non-supply to non-supply (i.e., I/O to I/O) stress to be limited to a
finite number of 2 pin pairs (coupled non-supply pin pairs);
h) explicit allowance for HBM stress using 2 pin HBM testers for die only shorted supply groups.

Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. CENELEC [and/or CEN] shall not be held responsible for identifying any or all such
patent rights.
Endorsement notice
The text of the International Standard IEC 60749-26:2013 was approved by CENELEC as a European
Standard without any modification.

- 3 - EN 60749-26:2014
Annex ZA
(normative)
Normative references to international publications
with their corresponding European publications

The following documents, in whole or in part, are normatively referenced in this document and are
indispensable for its application. For dated references, only the edition cited applies. For undated
references, the latest edition of the referenced document (including any amendments) applies.

NOTE 1 When an International Publication has been modified by common modifications, indicated by (mod), the relevant
EN/HD applies.
NOTE 2 Up-to-date information on the latest versions of the European Standards listed in this annex is available here:
www.cenelec.eu
Publication Year Title EN/HD Year

IEC 60749-27 - Semiconductor devices - Mechanical and EN 60749-27 -
climatic test methods -
Part 27: Electrostatic discharge (ESD)
sensitivity testing - Machine model (MM)

IEC 60749-26 ®
Edition 3.0 2013-04
INTERNATIONAL
STANDARD
NORME
INTERNATIONALE
colour
inside
Semiconductor devices – Mechanical and climatic test methods –

Part 26: Electrostatic discharge (ESD) sensitivity testing – Human body model

(HBM)
Dispositifs à semiconducteurs – Méthodes d'essais mécaniques et climatiques –

Partie 26: Essai de sensibilité aux décharges électrostatiques (DES) – Modèle du

corps humain (HBM)
INTERNATIONAL
ELECTROTECHNICAL
COMMISSION
COMMISSION
ELECTROTECHNIQUE
PRICE CODE
INTERNATIONALE
CODE PRIX X
ICS 31.080.01 ISBN 978-2-83220-746-8

– 2 – 60749-26 © IEC:2013
CONTENTS
FOREWORD . 4
1 Scope . 6
2 Normative references . 6
3 Terms and definitions . 6
4 Apparatus and required equipment . 9
4.1 Waveform verification equipment . 9
4.2 Oscilloscope . 10
4.3 Additional requirements for digital oscilloscopes . 10
4.4 Current transducer (inductive current probe) . 10
4.5 Evaluation loads . 10
4.6 Human body model simulator . 10
4.7 HBM test equipment parasitic properties . 11
5 Stress test equipment qualification and routine verification . 11
5.1 Overview of required HBM tester evaluations . 11
5.2 Measurement procedures . 11
5.2.1 Reference pin pair determination . 11
5.2.2 Waveform capture with current probe . 12
5.2.3 Determination of waveform parameters . 12
5.2.4 High voltage discharge path test . 15
5.3 HBM tester qualification . 15
5.3.1 HBM ESD tester qualification requirements . 15
5.3.2 HBM tester qualification procedure . 15
5.4 Test fixture board qualification for socketed testers . 16
5.5 Routine waveform check requirements . 17
5.5.1 Standard routine waveform check description . 17
5.5.2 Waveform check frequency . 17
5.5.3 Alternate routine waveform capture procedure . 18
5.6 High voltage discharge path check . 18
5.6.1 Relay testers . 18
5.6.2 Non-relay testers . 18
5.7 Tester waveform records . 18
5.7.1 Tester and test fixture board qualification records . 18
5.7.2 Periodic waveform check records . 18
5.8 Safety. 19
5.8.1 Initial set-up . 19
5.8.2 Training . 19
5.8.3 Personnel safety . 19
6 Classification procedure . 19
6.1 Devices for classification . 19
6.2 Parametric and functional testing . 19
6.3 Device stressing . 19
6.4 Pin categorization . 20
6.4.1 General . 20
6.4.2 No connect pins . 20
6.4.3 Supply pins . 20
6.4.4 Non–supply pins . 21

60749-26 © IEC:2013 – 3 –
6.5 Pin groupings . 21
6.5.1 Supply pin groups . 21
6.5.2 Shorted non-supply pin groups . 22
6.6 Pin stress combinations . 22
6.6.1 Pin stress combination categorisation . 22
6.6.2 Non-supply and supply to supply combinations (1, 2, … N) . 24
6.6.3 Non-supply to non-supply combinations . 25
6.7 Testing after stressing . 26
7 Failure criteria . 26
8 Component classification . 26
Annex A (informative) HBM test method flow chart . 27
Annex B (informative) HBM test equipment parasitic properties . 30
Annex C (informative) Example of testing a product using Table 2, Table 3, or Table 2
with a two-pin HBM tester . 34
Annex D (informative) Examples of coupled non-supply pin pairs . 40

Figure 1 – Simplified HBM simulator circuit with loads . 11
Figure 2 – Current waveform through shorting wires . 13
Figure 3 – Current waveform through a 500 Ω resistor . 14
Figure 4 – Peak current short circuit ringing waveform . 15
Figure B.1 – Diagram of trailing pulse measurement setup. 30
Figure B.2 – Positive stress at 4 000 V . 31
Figure B.3 – Negative stress at 4 000 V . 31
Figure B.4 – Illustration of measuring voltage before HBM pulse with a Zener diode or
a device . 32
Figure B.5 – Example of voltage rise before the HBM current pulse across a 9,4 V
Zener diode . 32
Figure C.1 – Example to demonstrate the idea of the partitioned test . 35

Table 1 – Waveform specification . 17
Table 2 – Preferred pin combinations sets . 23
Table 3 – Alternative pin combinations sets . 24
Table 4 – HBM ESD component classification levels . 26
Table C.1 – Product testing in accordance with Table 2 . 36
Table C.2 – Product testing in accordance with Table 3 . 37
Table C.3 – Alternative product testing in accordance with Table 2 . 38

– 4 – 60749-26 © IEC:2013
INTERNATIONAL ELECTROTECHNICAL COMMISSION
____________
SEMICONDUCTOR DEVICES –
MECHANICAL AND CLIMATIC TEST METHODS –

Part 26: Electrostatic discharge (ESD) sensitivity testing –
Human body model (HBM)
FOREWORD
1) The International Electrotechnical Commission (IEC) is a worldwide organization for standardization comprising
all national electrotechnical committees (IEC National Committees). The object of IEC is to promote
international co-operation on all questions concerning standardization in the electrical and electronic fields. To
this end and in addition to other activities, IEC publishes International Standards, Technical Specifications,
Technical Reports, Publicly Available Specifications (PAS) and Guides (hereafter referred to as “IEC
Publication(s)”). Their preparation is entrusted to technical committees; any IEC National Committee interested
in the subject dealt with may participate in this preparatory work. International, governmental and non-
governmental organizations liaising with the IEC also participate in this preparation. IEC collaborates closely
with the International Organization for Standardization (ISO) in accordance with conditions determined by
agreement between the two organizations.
2) The formal decisions or agreements of IEC on technical matters express, as nearly as possible, an international
consensus of opinion on the relevant subjects since each technical committee has representation from all
interested IEC National Committees.
3) IEC Publications have the form of recommendations for international use and are accepted by IEC National
Committees in that sense. While all reasonable efforts are made to ensure that the technical content of IEC
Publications is accurate, IEC cannot be held responsible for the way in which they are used or for any
misinterpretation by any end user.
4) In order to promote international uniformity, IEC National Committees undertake to apply IEC Publications
transparently to the maximum extent possible in their national and regional publications. Any divergence
between any IEC Publication and the corresponding national or regional publication shall be clearly indicated in
the latter.
5) IEC itself does not provide any attestation of conformity. Independent certification bodies provide conformity
assessment services and, in some areas, access to IEC marks of conformity. IEC is not responsible for any
services carried out by independent certification bodies.
6) All users should ensure that they have the latest edition of this publication.
7) No liability shall attach to IEC or its directors, employees, servants or agents including individual experts and
members of its technical committees and IEC National Committees for any personal injury, property damage or
other damage of any nature whatsoever, whether direct or indirect, or for costs (including legal fees) and
expenses arising out of the publication, use of, or reliance upon, this IEC Publication or any other IEC
Publications.
8) Attention is drawn to the Normative references cited in this publication. Use of the referenced publications is
indispensable for the correct application of this publication.
9) Attention is drawn to the possibility that some of the elements of this IEC Publication may be the subject of
patent rights. IEC shall not be held responsible for identifying any or all such patent rights.
International Standard IEC 60749-26 has been prepared by IEC technical committee 47:
Semiconductor devices in collaboration with technical committee 101.
This third edition cancels and replaces the second edition published in 2006. This edition
constitutes a technical revision. This standard is based upon ANSI/ESDA/JEDEC JS-001-
2010. It is used with permission of the copyright holders, ESD Association and JEDEC Solid
state Technology Association.
NOTE ANSI/ESDA/JEDEC JS-001 resulted from the merging of JESD22-A114F and ANSI/ESD STM5.1.
This edition includes the following significant technical changes with respect to the previous
edition:
a) descriptions of oscilloscope and current transducers have been refined and updated;
b) the HBM circuit schematic and description have been improved;

60749-26 © IEC:2013 – 5 –
c) the description of stress test equipment qualification and verification has been completely
re-written;
d) qualification and verification of test fixture boards has been revised;
e) a new section on the determination of ringing in the current waveform has been added;
f) some alternate pin combinations have been included;
g) allowance for non-supply pins to stress to a limited number of supply pin groups
(associated non-supply pins) and allowance for non-supply to non-supply (i.e., I/O to I/O)
stress to be limited to a finite number of 2 pin pairs (coupled non-supply pin pairs);
h) explicit allowance for HBM stress using 2 pin HBM testers for die only shorted supply
groups.
The text of this standard is based on the following documents:
FDIS Report on voting
47/2160/FDIS 47/2167/RVD
Full information on the voting for the approval of this standard can be found in the report on
voting indicated in the above table.
This publication has been drafted in accordance with the ISO/IEC Directives, Part 2.
A list of all parts in the IEC 60749 series, published under the general title Semiconductor
devices – Mechanical and climatic test methods, can be found on the IEC website.
The committee has decided that the contents of this publication will remain unchanged until
the stability date indicated on the IEC web site under "http://webstore.iec.ch" in the data
related to the specific publication. At this date, the publication will be
• reconfirmed,
• withdrawn,
• replaced by a revised edition, or
• amended.
IMPORTANT – The 'colour inside' logo on the cover page of this publication indicates
that it contains colours which are considered to be useful for the correct
understanding of its contents. Users should therefore print this document using a
colour printer.
– 6 – 60749-26 © IEC:2013
SEMICONDUCTOR DEVICES –
MECHANICAL AND CLIMATIC TEST METHODS –

Part 26: Electrostatic discharge (ESD) sensitivity testing –
Human body model (HBM)
1 Scope
This standard establishes the procedure for testing, evaluating, and classifying components
and microcircuits according to their susceptibility (sensitivity) to damage or degradation by
exposure to a defined human body model (HBM) electrostatic discharge (ESD).
The purpose (objective) of this standard is to establish a test method that will replicate HBM
failures and provide reliable, repeatable HBM ESD test results from tester to tester,
regardless of component type. Repeatable data will allow accurate classifications and
comparisons of HBM ESD sensitivity levels.
ESD testing of semiconductor devices is selected from this test method, the machine model
(MM) test method (see IEC 60749-27) or other ESD test methods in the IEC 60749 series.
The HBM and MM test methods produce similar but not identical results; unless otherwise
specified, this test method is the one selected.
2 Normative references
The following documents, in whole or in part, are normatively referenced in this document and
are indispensable for its application. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any
amendments) applies.
IEC 60749-27, Semiconductor devices – Mechanical and climatic test methods – Part 27:
Electrostatic discharge (ESD) sensitivity testing – Machine model (MM)
3 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
3.1
associated non-supply pin
non-supply pin (typically an I/O pin) associated with a supply pin group
Note 1 to entry: A non-supply pin is considered to be associated with a supply pin group if either:
a) The current from the supply pin group (i.e., VDDIO) is required for the function of the electrical circuit(s) (I/O
driver) that connect (high/low impedance) to that non-supply pin.
b) A parasitic path exists between non-supply and supply pin group (e.g., open-drain type non-supply pin to a
VCC supply pin group that connects to a nearby N-well guard ring).
3.2
component
item such as a resistor, diode, transistor, integrated circuit or hybrid circuit

60749-26 © IEC:2013 – 7 –
3.3
component failure
condition in which a tested component does not meet one or more specified static or dynamic
data sheet parameters
3.4
coupled non-supply pin pair
two pins that have an intended direct current path (such as a pass gate or resistors, such as
differential amplifier inputs, or low voltage differential signaling (LVDS) pins), including
analogue and digital differential pairs and other special function pairs (e.g., D+/D-,
XTALin/XTALout, RFin/RFout, TxP/TxN, RxP/RxN, CCP_DP/CCN_DN etc.)
3.5
data sheet parameters
static and dynamic component performance data supplied by the component manufacturer or
supplier
3.6
withstand voltage
highest voltage level that does not cause device failure
Note 1 to entry: The device passes all tested lower voltages (see failure Window).
3.7
failure window
intermediate range of stress voltages that can induce failure in a particular device type, when
the device type can pass some stress voltages both higher and lower than this range
Note 1 to entry: A component with a failure window may pass a 500 V test, fail a 1 000 V test and pass 2 000 V
test. The withstand voltage of this device is 500 V.
3.8
human body model electrostatic discharge
HBM ESD
ESD event meeting the waveform criteria specified in this standard, approximating the
discharge from the fingertip of a typical human being to a grounded device
3.9
HBM ESD tester
HBM simulator
equipment that applies an HBM ESD to a component
3.10
I
ps
peak current value determined by the current at time t on the linear extrapolation of the
max
exponential current decay curve, based on the current waveform data over a 40 nanosecond
period beginning at t
max
SEE: Figure 2 a).
3.11
I
psmax
highest current value measured including the overshoot or ringing components due to internal
test simulator RLC parasitics
SEE: Figure 2 a).
3.12
no connect pin
package interconnection that is not electrically connected to a die

– 8 – 60749-26 © IEC:2013
EXAMPLE: Pin, bump, ball interconnection.
Note 1 to entry: There are some pins which are labelled as no connect, which are actually connected to the die
and should not be classified as a no connect pin.
3.13
non-socketed tester
HBM simulator that makes contact to the device under test (DUT), pins (or balls, lands, bumps
or die pads) with test probes rather than placing the DUT in a socket
3.14
non-supply pins
all pins not categorized as supply pins or no connects
Note 1 to entry: This includes pins such as input, output, offset adjusts, compensation, clocks, controls, address,
data, Vref pins and VPP pins on EPROM memory. Most non-supply pins transmit or receive information such as
digital or analog signals, timing, clock signals, and voltage or current reference levels.
3.15
package plane
low impedance metal layer built into an IC package connecting a group of bumps or pins
(typically power or ground)
Note 1 to entry: There may be multiple package planes (sometimes referred to as islands) for each power and
ground group.
3.16
pre-pulse voltage
voltage occurring at the device under test (DUT) just prior to the generation of the HBM
current pulse
SEE: Clause C.2.
3.17
pulse generation circuit
dual polarity pulse source circuit network that produces a human body discharge current
waveform
Note 1 to entry: The circuit network includes a pulse generator with its test equipment internal path up to the
contact pad of the test fixture. This circuit is also referred to as dual polarity pulse source.
3.18
ringing
high frequency oscillation superimposed on a waveform
3.19
shorted non-supply pin
any non-supply pin (typically an I/O pin) that is metallically connected (typically < 3 Ω) on the
chip or within the package to another non-supply pin (or set of non-supply pins)
3.20
spurious current pulses
small HBM shaped pulses that follow the main current pulse, and are typically defined as a
percentage of I
psmax
3.21
socketed tester
an HBM simulator that makes contact to DUT pins (or balls, lands, bumps or die pads) using a
DUT socket mounted on a test fixture board

60749-26 © IEC:2013 – 9 –
3.22
static parameters
parameters measured with the component in a non-operating condition
Note 1 to entry: These may include, but are not limited to, input leakage current, input breakdown voltage, output
high and low voltages, output drive current, and supply current.
3.23
step stress test hardening
ability of a component subjected to increasing ESD voltage stresses to withstand higher
stress levels than a similar component not previously stressed
EXAMPLE: A component may fail at 1 000 V if subjected to a single stress, but fail at 3 000 V if stressed
incrementally from 250 V.
3.24
supply pin
any pin that provides current to a circuit
Note 1 to entry: Supply pins typically transmit no information (such as digital or analogue signals, timing, clock
signals, and voltage or current reference levels). For the purpose of ESD testing, power and ground pins are
treated as supply pins.
3.25
test fixture board
specialized circuit board, with one or more component sockets, which connects the DUT(s) to
the HBM simulator
3.26
t
max
time when I is at its maximum value (I )
ps psmax
SEE: Figure 2a).
3.27
trailing current pulse
current pulse that occurs after the HBM current pulse has decayed
SEE: Clause C.1.
Note 1 to entry: A trailing current pulse is a relatively constant current often lasting for hundreds of microseconds.
3.28
two pin tester
A low parasitic HBM simulator that tests DUTs in pin pairs where floating pins are not
connected to the simulator thereby eliminating DUT-tester interactions from parasitic tester
loading of floating pins
4 Apparatus and required equipment
4.1 Waveform verification equipment
All equipment used to evaluate the tester shall be calibrated in accordance with the
manufacturer's recommendation. This includes the oscilloscope, current transducer and high
voltage resistor load. Maximum time between calibrations shall be one year. Calibration shall
be traceable to national or international standards.
Equipment capable of verifying the pulse waveforms defined in this standard test method
includes, but is not limited to, an oscilloscope, evaluation loads and a current transducer.

– 10 – 60749-26 © IEC:2013
4.2 Oscilloscope
A digital oscilloscope is recommended but analogue oscilloscopes are also permitted. In order
to ensure accurate current waveform capture, the oscilloscope shall meet the following
requirements:
a) Minimum sensitivity of 100 mA per major division when used in conjunction with the
current transducer specified in 4.4;
b) Minimum bandwidth of 350 MHz;
c) For analogue scopes, minimum writing rate of one major division per nanosecond.
4.3 Additional requirements for digital oscilloscopes
Where a digital oscilloscope is used the following additional requirements apply:
a) Recommended channels: 2 or more;
b) Minimum sampling rate: 10 samples per second;
c) Minimum vertical resolution: 8-bit;
d) Minimum vertical accuracy: ± 2,5 %;
e) Minimum time base accuracy: 0,01 %;
f) Minimum record length: 10 k points.
4.4 Current transducer (inductive current probe)
a) Minimum bandwidth of 200 MHz;
b) Peak pulse capability of 12 A;
c) Rise time of less than 1 ns;
d) Capable of accepting a solid conductor as specified in 4.5;
e) Provides an output voltage per signal current as required in 4.2
(This is usually between 1 mV/mA and 5 mV/mA.);
f) Low-frequency 3 dB point below 10 kHz (e.g., Tektronix CT2) for measurement of decay
constant t (see 5.2.3.2, Table 1, and Note below).
d
NOTE Results using a current probe with a low-frequency 3 dB point of 25 kHz (e.g., Tektronix CT1) to measure
decay constant t are acceptable if t is found to be between 130 ns and 165 ns.
d d
4.5 Evaluation loads
Two evaluation loads are necessary to verify tester functionality:
a) Load 1: A solid 18 – 24 AWG (non-US standard wire size 0,25 to 0,75 mm cross-section)
tinned copper shorting wire as short as practicable to span the distance between the two
farthest pins in the socket while passing through the current probe or long enough to pass
through the current probe and contacted by the probes of the non-socketed tester.
b) Load 2: A 500 Ω, ± 1 %, minimum 4 000 voltage rating.
4.6 Human body model simulator
A simplified schematic of the HBM simulator or tester is given in Figure 1. The performance of
the tester is influenced by parasitic capacitance and inductance. Thus, construction of a tester
using this schematic does not guarantee that it will provide the HBM pulse required for this
standard. The waveform capture procedures and requirements described in Clause 5
determine the acceptability of the equipment for use.

60749-26 © IEC:2013 – 11 –
Dual polarity
pulse source
Terminal
S1
R1 ≥ 1 MΩ R2 ∼ 1 500 Ω A
Dual polarity
C1 ∼ 100 pF
HV supply
Terminal
B
Current
probes
IEC  893/13
Figure 1 – Simplified HBM simulator circuit with loads
The charge removal circuit shown in Figure 1 ensures a slow discharge of the device, thus
avoiding the possibility of a charged device model discharge. A simple example is a 10 kΩ or
larger resistor (possibly in series with a switch) in parallel with the test fixture board. This
resistor may also be useful to control parasitic pre-pulse voltages (See Annex C). The dual
polarity pulse generator (source) shall be designed to avoid recharge transients and double
pulses. It should be noted that reversal of terminals A and B to achieve dual polarity
performance is not permitted. Stacking of DUT socket adapters (piggybacking or insertion of
secondary sockets into the main test socket) is allowed only if the secondary socket waveform
meets the requirements of this standard defined in Table 1.
NOTE 1 The current transducers (probes) are specified in 4.4.
NOTE 2 The shorting wire (short) and 500 Ω resistor (R4) are evaluation loads specified in 4.5.
NOTE 3 Component values are nominal.
4.7 HBM test equipment parasitic properties
Some HBM simulators have been found to falsely classify HBM sensitivity levels due to
parasitic artifacts or uncontrolled voltages unintentionally built into the HBM simulators.
Methods for determining if these effects are present and optional mitigation techniques are
described in Annex C. Two-pin testers and non-socketed testers may have smaller parasitic
capacitances and may reduce the effects of tester parasitics by contacting only the pins being
stressed.
5 Stress test equipment qualification and routine verification
5.1 Overview of required HBM tester evaluations
The HBM tester and test fixture boards shall be qualified, re-qualified, and periodically verified
as described in this clause. The safety precautions described in 5.8 shall be followed at all
times.
5.2 Measurement procedures
5.2.1 Reference pin pair determination
The two pins of each socket on a test fixture board which make up the reference pin pair are
(1) the socket pin with the shortest wiring path of the test fixture to the pulse generation circuit
(terminal B) and (2) the socket pin with the longest wiring path of the test fixture from the
pulse generation circuit (terminal A) to the ESD stress socket (See Figure 1). This information
is typically provided by the equipment or test fixture board manufacturer. If more than one
pulse generation circuit is connected to a socket then there will be more than one reference
pin pair.
Charge
removal
circuit
Test
fixture
board
Short
R4 =
500 Ω
DUT
– 12 – 60749-26 © IEC:2013
It is strongly recommended that on non-positive clamp fixtures, feed through test point pads
be added on these paths to allow connection of either the shorting wire or 500 Ω load resistor
during waveform verification measurements. These test points should be added as close as
possible to the socket(s), and if the test fixture board uses more than one pulse generator,
multiple feed through test points should be added for each pulse generator’s longest and
shortest paths.
NOTE A positive clamp test socket is a zero insertion force (ZIF) socket with a clamping mechanism. It allows the
shorting wire to be easily clamped into the socket. Examples are dual in-line package (DIP) and pin grid array
(PGA) ZIF sockets.
5.2.2 Waveform capture with current probe
5.2.2.1 General
To capture a current waveform between two socket pins (usually the reference pin pair), use
the shorting wire (4.5, Load 1) for the short circuit measurement or the 500 Ω resistor (4.5,
Load 2) for the 500 Ω current measurement and the inductive current probe (4.4).
5.2.2.2 Short circuit current waveform
Attach the shorting wire between the pins to be measured. Place the current probe around the
shorting wire, as close to terminal B as practical, observing the polarity shown in Figure 1.
Apply an ESD stress at the voltage and polarity needed to execute the qualification, re-
qualification or periodic verification being conducted.
a) For positive clamp sockets, insert the shorting wire between the socket pins connected to
terminals A and B and hold in place by closing the clamp.
b) For non-positive clamp sockets, attach the shorting wire between the socket pins
connected to terminals A and B. If it is not possible to make contact within the socket,
connect the shorting wire between the reference pin pair test points or socket mounting
holes, if available. The design of the socket is important as some socket types may
include contact springs (coils) in their design. These springs can add more parasitic
inductance to the signal path and may affect the HBM waveform. Selecting sockets that
minimize the use of springs (coils) is recommended, but if this is not possible, then
keeping their length as short as possible is recommended.
c) For non-socketed testers, the shorting wire with the inductive current probe is placed on
an insulating surface and the simulator terminal A and terminal B probes are placed on the
ends of the wires.
5.2.2.3 500 Ω load current waveform
Place the current probe around the 500 Ω resistor’s lead, observing the polarity as shown in
Figure 1. Attach the 500 Ω resistor between the pins to be measured. The current probe shall
be placed around the wire between the resistor and terminal B. Apply an ESD stress at the
voltage and polarity needed to execute the qualification, re-qualification or periodic
verification being conducted.
a) For socketed testers, follow procedures according to socket type as described in 5.2.2.2.
b) For non-socketed testers, place the test load and current probe on an insulating surface
and connect the tester’s probes to the ends of the test load.
5.2.3 Determination of waveform parameters
5.2.3.1 Use of waveforms
The captured waveforms are used to determine the parameter values listed in Table 1.

60749-26 © IEC:2013 – 13 –
5.2.3.2 Short circuit waveform
Typical short circuit waveforms are shown in Figures 2a), 2b) and 4. The parameters I (peak
ps
current), t (pulse rise time), t (pulse decay time) and I (ringing) are determined from these
r d R
waveforms. Ringing may prevent the simple determination of I A graphical technique for
ps.
determining I and I is described in 5.2.3.4 and Figure 4.
ps R
5.2.3.3 500 Ω load waveform
A typical 500 Ω load waveform is shown in Figure 3. The parameters I (peak current with
pr
(pulse rise time with 500 Ω load) are determined from this waveform.
500 Ω load) and t
rr
I
psmax
I
ps
90 % I
ps
10 % I
ps
Time  (ns)
t
r
40 ns
5 ns per division
t
max
IEC  894/1 3
a) Current waveform through a shorting wire (I )
psmax
I
ps
36,8 % I
ps
Time  (ns)
100 ns per division
t
d
t
max
IEC  895/13
b) Current waveform through a shorting wire (t )
d
Figure 2 – Current waveform through shorting wires
Current  (A) Current  (A)
– 14 – 60749-26 © IEC:2013
I
pr
90 % I
pr
10 % I
pr
0 Time  (ns)
t
rr
5 ns per division
IEC  896/13
Figure 3 – Current waveform through a 500 Ω resistor
5.2.3.4 Graphical determination of I and I (see Figure 4)
ps R
5.2.3.4.1 A line is drawn (manually or using numerical methods such as least squares)
through the HBM ringing waveform from t to t + 40 ns to interpolate the value of the
max max
curve for a more accurate derivation of the peak current value (I ). t is the time when
ps max
I occurs (see definition for t in Clause 3 and Figure 2a)).
psmax max
5.2.3.4.2 The maximum deviation of the measured current above the straight line fit is Ring1.
The maximum deviation of the measured current below the straight line fit is Ring2. The
maximum ringing current during a short circuit waveform measurement is defined as:
= |Ring1| + |Ring2|
I
R
Current  (mA)
60749-26 © IEC:2013 – 15 –
1,68
1,66
1,64
1,62
1,60
1,58
1,56
1,54
1,52
1,50
I
psmax
1,48
1,46
I
ps
1,44
1,42
1,40
1,38
Ring2 Ring1
1,36
1,34
1,32
I = |Ring1| + |Ring2|
R
1,30
1,28
1,26
1,24
1,22
1,20
1,18
0 2,5 5,0 7,5 10,0 12,5 15,0 17,5 20,0 22,5 25,0
Time  (ns)
IEC  897/13
Figure 4 – Peak current short circuit ringing waveform
5.2.4 High voltage discharge path test
This test is only required for relay-based testers. This test is intended to ensure that the tester
high voltage relays and the grounding relays that connect pulse generator(s) (i.e. terminal A)
and current return paths (i.e. terminal B) to the DUT are functioning properly. The tester
manufacturer should provide a recommended procedure and if needed, a verification board
and software.
5.3 HBM tester qualification
5.3.1 HBM ESD tester qualification requirements
HBM ESD tester qualification as described in 5.3 is required in the following situations:
a) Acceptance testing when the ESD tester is delivered or first used.
b) Periodic re-qualification in accordance with manufacturer’s recommendations. The
maximum time between re-qualification tests is one year.
c) After service or repair that could affect the waveform.
5.3.2 HBM tester qualification procedure
5.3.2.1 Test fixture board, socket and pins for socketed t
...
