EN 15420:2010
(Main)Gas-fired central heating boilers - Type C boilers of nominal heat input exceeding 70 kW, but not exceeding 1 000 kW
Gas-fired central heating boilers - Type C boilers of nominal heat input exceeding 70 kW, but not exceeding 1 000 kW
This document specifies the requirements and test methods concerning, in particular, the construction, safety, fitness for purpose, and rational use of energy, as well as the classification and marking of gas-fired central heating boilers that are fitted with atmospheric burners, fan-assisted atmospheric burners or fully premixed burners, and are hereafter referred to as "boilers".
This document applies to boilers of type C, as listed in 4.2:
- that use one or more combustible gases of the three gas families at the pressures stated in Tables 14 and 15;
- that have a nominal heat input (on the basis of net calorific value) exceeding 70 kW, but not exceeding 1 000 kW, including modular boilers;
- where the temperature of the heat transfer fluid does not exceed 105 °C during normal operation;
- where the maximum operating pressure in the water circuit does not exceed 6 bar;
- which can give rise to condensation under certain circumstances.
The document applies to boilers designed for sealed water systems or for open water systems.
The document does not contain all the requirements necessary for boilers:
- intended to be installed in the open or in living rooms;
- permanently fitted with more than one flue outlet;
- of the condensing type;
- intended to be connected to a common flue having mechanical extraction;
- type C21, C41, C51, C61, C7 and C81 boilers;
- fitted with a forced draught burner in accordance with EN 676;
- producing hot water for domestic purposes.
This document only covers type testing.
Heizkessel für gasförmige Brennstoffe - Heizkessel der Bauart C mit einer Nennwärmebelastung größer als 70 kW aber gleich oder kleiner als 1 000 kW
Diese Norm legt die Anforderungen und die Prüfmethoden fest im Hinblick auf die Konstruktion, die Sicherheit,
die Gebrauchstauglichkeit und den wirtschaftlichen Einsatz von Energie sowie die Klassifizierung und die
Kennzeichnung von gasbeheizten Zentralheizungskesseln mit atmosphärischen Brennern, mit gebläseunterstützten
atmosphärischen Brennern oder mit voll vorgemischten Brennern, die im weiteren Verlauf als
„Kessel“ bezeichnet werden.
Diese Norm behandelt, wie in 4.2 aufgelistet, Kessel der Bauart C:
die ein oder mehrere Brenngase der drei Gasfamilien bei den in den Tabellen 14 und 15 angegebenen
Drücken verwenden;
die Nennwärmebelastung (bezogen auf den Heizwert) über 70 kW, aber nicht über 1 000 kW (einschließlich
der Kombikessel) haben;
bei denen die Temperatur der Wärme übertragenden Flüssigkeit beim üblichen Betrieb 105 °C nicht
überschreitet;
bei denen der höchste Betriebsdruck im Wasserkreislauf 6 bar nicht überschreitet;
bei denen unter bestimmten Umständen Kondensation eintreten kann.
Die Norm gilt sowohl für Kessel mit geschlossenem als auch mit offenem Wasserkreislauf.
Diese Norm enthält nicht alle für Kessel erforderlichen Anforderungen:
die im Freien oder in Wohnräumen aufgestellt werden;
die dauerhaft mit mehr als einem Abgasstutzen ausgerüstet sind;
der Bauart „Brennwertkessel“;
die an eine gemeinsame Abgasanlage mit mechanischer Abgasabführung anzuschließen sind;
der Bauarten C21, C41, C51, C61, C71 und C81;
die in Übereinstimmung mit EN 676 mit einem Gebläsebrenner ausgerüstet sind;
die Warmwasser für den sanitären Bedarf erzeugen.
Diese Norm gilt nur für Typprüfungen.
Chaudières de chauffage central utilisant les combustibles gazeux - Chaudières de type C dont le débit calorifique nominal est supérieur à 70 kW mais inférieur ou égal à 1 000 kW
Le présent document spécifie les exigences et les méthodes d’essai concernant les chaudières de chauffage central utilisant les combustibles gazeux et équipées de brûleurs atmosphériques, de brûleurs atmosphériques assistés d’un ventilateur ou de brûleurs à prémélange total, ci-après dénommées « chaudières », en particulier leur conception, leur sécurité, leur aptitude à la fonction, leur utilisation rationnelle de l’énergie, ainsi que leur classification et leur marquage.
Le présent document s’applique aux chaudières de type C, telles qu’énumérées en 4.2 :
- utilisant un ou plusieurs combustibles gazeux appartenant aux trois familles de gaz et aux pressions indiquées dans les Tableaux 14 et 15 ;
- de débit calorifique nominal (sur pouvoir calorifique inférieur) compris entre 70 kW et 1 000 kW, y compris les chaudières modulaires ;
- dont la température du fluide caloporteur ne dépasse pas 105 °C en fonctionnement normal ;
- dont la pression maximale de service dans le circuit d’eau ne dépasse pas 6 bar ;
- pouvant provoquer une condensation dans certaines circonstances.
Le présent document s’applique aux chaudières à circuit d’eau fermé ou ouvert.
Le document ne contient pas toutes les exigences nécessaires pour les chaudières :
- destinées à être installées en plein air ou dans des locaux d’habitation ;
- dotées de manière permanente de plusieurs conduits d’évacuation des produits de combustion ;
- à condensation ;
- destinées à être raccordées à une cheminée commune à extraction mécanique ;
- de type C21, C41, C51, C61, C7 et C81 ;
- dotées d’un brûleur à air soufflé conforme à l’EN 676 ;
- produisant de l’eau chaude pour usage domestique.
Le présent document couvre uniquement les essais de type.
Plinski kotli za centralno gretje - Tip kotlov C z imensko močjo nad 70 kW do vključno 1000 kW
Ta dokument določa zahteve in preskusne metode, ki zlasti zadevajo izgradnjo, varnost, zahteve za uporabnost in racionalno uporabo energije, kot tudi klasifikacijo in označevanje plinskih kotlov za centralno ogrevanje, ki so opremljeni z atmosferskimi gorilniki, z atmosferskimi gorilniki z ventilatorjem ali v celoti vnaprej pripravljeni gorilniki, v nadaljevanju »kotli«.
Ta dokument velja za kotle tipa C, kot so navedeni v točki 4.2:
- ki uporabljajo enega ali več vnetljivih plinov iz treh družin plinov pri tlakih, navedenih v preglednicah 14 in 15.
- ki imajo nazivni dovod toplote (na osnovi neto kalorične vrednosti), ki presega 70 kW, vendar ne presega 1000 kW, vključno z modularnimi kotli;
- kjer temperatura tekočine za prenos toplote ne presega 105 °C med običajnim delovanjem;
- kjer najvišji obratovalni tlak v vodnem tokokrogu ne presega 6 barov;
- ki lahko pod določenimi okoliščinami povzročijo kondenzacijo.
Ta dokument velja za kotle, načrtovane za zaprte vodne sisteme, ali za odprte vodne sisteme.
Ta dokument ne vsebuje vseh zahtev, potrebnih za kotle:
- namenjene namestitvi v odprt prostor ali dnevni prostor;
- na katere je stalno nameščen več kot en izhod dimnika;
- kondenzacijskega tipa;
- namenjene povezavi s skupnim dimnikom z mehansko ekstrakcijo;
- tipa C21, C41, C51, C61, C7 in C81;
- opremljene z gorilniki na prisilni vlek v skladu z EN 676;
- ki proizvajajo vročo vodo za gospodinjstva. Ta dokument zajem zgolj tipsko preskušanje.
General Information
- Status
- Withdrawn
- Publication Date
- 30-Nov-2010
- Withdrawal Date
- 23-Oct-2012
- Technical Committee
- CEN/TC 109 - Central heating boilers using gaseous fuels
- Current Stage
- 9960 - Withdrawal effective - Withdrawal
- Start Date
- 24-Oct-2012
- Completion Date
- 24-Oct-2012
Relations
- Effective Date
- 31-Oct-2012
- Effective Date
- 28-Jan-2026
Get Certified
Connect with accredited certification bodies for this standard
ICC Evaluation Service
Nonprofit organization that performs technical evaluations of building products.
Aboma Certification B.V.
Specialized in construction, metal, and transport sectors.
BBA (British Board of Agrément)
UK construction product certification.
Sponsored listings
Frequently Asked Questions
EN 15420:2010 is a standard published by the European Committee for Standardization (CEN). Its full title is "Gas-fired central heating boilers - Type C boilers of nominal heat input exceeding 70 kW, but not exceeding 1 000 kW". This standard covers: This document specifies the requirements and test methods concerning, in particular, the construction, safety, fitness for purpose, and rational use of energy, as well as the classification and marking of gas-fired central heating boilers that are fitted with atmospheric burners, fan-assisted atmospheric burners or fully premixed burners, and are hereafter referred to as "boilers". This document applies to boilers of type C, as listed in 4.2: - that use one or more combustible gases of the three gas families at the pressures stated in Tables 14 and 15; - that have a nominal heat input (on the basis of net calorific value) exceeding 70 kW, but not exceeding 1 000 kW, including modular boilers; - where the temperature of the heat transfer fluid does not exceed 105 °C during normal operation; - where the maximum operating pressure in the water circuit does not exceed 6 bar; - which can give rise to condensation under certain circumstances. The document applies to boilers designed for sealed water systems or for open water systems. The document does not contain all the requirements necessary for boilers: - intended to be installed in the open or in living rooms; - permanently fitted with more than one flue outlet; - of the condensing type; - intended to be connected to a common flue having mechanical extraction; - type C21, C41, C51, C61, C7 and C81 boilers; - fitted with a forced draught burner in accordance with EN 676; - producing hot water for domestic purposes. This document only covers type testing.
This document specifies the requirements and test methods concerning, in particular, the construction, safety, fitness for purpose, and rational use of energy, as well as the classification and marking of gas-fired central heating boilers that are fitted with atmospheric burners, fan-assisted atmospheric burners or fully premixed burners, and are hereafter referred to as "boilers". This document applies to boilers of type C, as listed in 4.2: - that use one or more combustible gases of the three gas families at the pressures stated in Tables 14 and 15; - that have a nominal heat input (on the basis of net calorific value) exceeding 70 kW, but not exceeding 1 000 kW, including modular boilers; - where the temperature of the heat transfer fluid does not exceed 105 °C during normal operation; - where the maximum operating pressure in the water circuit does not exceed 6 bar; - which can give rise to condensation under certain circumstances. The document applies to boilers designed for sealed water systems or for open water systems. The document does not contain all the requirements necessary for boilers: - intended to be installed in the open or in living rooms; - permanently fitted with more than one flue outlet; - of the condensing type; - intended to be connected to a common flue having mechanical extraction; - type C21, C41, C51, C61, C7 and C81 boilers; - fitted with a forced draught burner in accordance with EN 676; - producing hot water for domestic purposes. This document only covers type testing.
EN 15420:2010 is classified under the following ICS (International Classification for Standards) categories: 91.140.10 - Central heating systems. The ICS classification helps identify the subject area and facilitates finding related standards.
EN 15420:2010 has the following relationships with other standards: It is inter standard links to EN 15502-2-1:2012, EN ISO 19125-2:2006. Understanding these relationships helps ensure you are using the most current and applicable version of the standard.
EN 15420:2010 is associated with the following European legislation: EU Directives/Regulations: 2009/142/EC, 90/396/EEC; Standardization Mandates: M/BC/CEN/89/6. When a standard is cited in the Official Journal of the European Union, products manufactured in conformity with it benefit from a presumption of conformity with the essential requirements of the corresponding EU directive or regulation.
EN 15420:2010 is available in PDF format for immediate download after purchase. The document can be added to your cart and obtained through the secure checkout process. Digital delivery ensures instant access to the complete standard document.
Standards Content (Sample)
