EN 14910:2007

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Garden equipment - Walk-behind combustion engine powered trimmers - SafetyMatériel de jardinage - Coupe-gazon a moteur et a conducteur a pied - SécuritéGartengeräte - Handgeführte Trimmer mit Verbrennungsmotor - SicherheitTa slovenski standard je istoveten z:EN 14910:2007SIST EN 14910:2007en,fr,de65.060.70Vrtnarska opremaHorticultural equipmentICS:SLOVENSKI
STANDARDSIST EN 14910:200701-september-2007

EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 14910May 2007ICS 65.060.70 English VersionGarden equipment - Walk-behind combustion engine poweredtrimmers - SafetyMatériel de jardinage - Coupe-gazon à moteur et àconducteur à pied - SécuritéGartengeräte - Handgeführte Trimmer mitVerbrennungsmotor - SicherheitThis European Standard was approved by CEN on 22 March 2007.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the CEN Management Centre or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as theofficial versions.CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland,France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal,Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre: rue de Stassart, 36
B-1050 Brussels© 2007 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 14910:2007: E

Vibration (see 5.10).28 A.1 Quantities to be measured.28 A.2 Instrumentation.28 A.2.1 General.28 A.2.2 Fastening of transducer.28 A.2.3 Calibration.28 A.3 Measurement direction and measurement location.28 A.3.1 Measurement direction.28 A.3.2 Measurement location.28 A.4 Test procedure.29 A.4.1 Determination of working procedure.29 A.4.2 Test method.29 A.5 Measurement procedure.29 A.6 Determination of the measurement result.29 Annex B (normative)
Noise test code — Engineering method (grade 2) (see 5.11).32 B.1 General.32 B.2 Scope.32 B.3 Sound power level determination.32 B.4 A-weighted emission sound pressure level determination.34 B.5 Requirements for test floor.34 B.5.1 Artificial surface.34 B.5.2 Natural grass.35 B.6 Installation, mounting and operating conditions.35 B.7 Information to be recorded and reported.36 B.8 Measurement uncertainties and declaration of noise emission values.36 Annex C (informative)
Example of a material and construction fulfilling the requirements for an artificial surface as required by B.5.1.37 C.1 Material.37 C.2 Construction.37 Annex D (normative)
Calculation of kinetic energy (see 5.12.1).39 Annex E (normative)
Safety signs for use on trimmers (see 6.2.2).40 Annex F (informative)
Safety instructions.43 F.1 Introduction.43 F.2 General provisions.43 F.3 Safe operating practices.43 F.3.1 Training.43 F.3.2 Preparation.43 F.3.3 Operation.44 F.3.4 Maintenance and storage.45 Annex ZA (informative)
Relationship between this European Standard and the Essential Requirements of EU Directive 98/37/EC, amended by Directive 98/79/EC.46 Bibliography.47

EN 836 applies for machines using non-metallic filament line or freely pivoting non-metallic cutting elements with greater than 10 J kinetic energy. d) motor mowers using metal or other solid cutting elements. NOTE 2 EN 12733 applies for machines using metal or other solid cutting elements. EMC and environmental hazards other than noise have not been considered in this European Standard. This European Standard is not applicable to walk-behind trimmers which are manufactured before the date of its publication as EN. NOTE 3 Lawn trimmers and lawn edge trimmers (electric powered) are dealt with in EN 786, grass trimmers (internal combustion engine powered) are dealt with in EN 11806 and lawn mowers (internal combustion engine powered) are dealt with in EN 836. 2 Normative references The following referenced documents are indispensable for the application of this European Standard. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. EN 294:1992, Safety of machinery — Safety distance to prevent danger zones being reached by the upper limbs EN 1033:1995, Hand-arm vibration — Laboratory measurement of vibration at the grip surface of hand-guided machinery — General EN ISO 354:2003, Acoustics — Measurement of sound absorption in a reverberation room (ISO 354:2003) EN ISO 3744:1995, Acoustics — Determination of sound power levels of noise sources using sound pressure — Engineering method in an essentially free field over a reflecting plane (ISO 3744:1994) EN ISO 11201:1995, Acoustics — Noise emitted by machinery and equipment — Measurement of emission sound pressure levels at a work station and at other specified positions — Engineering method in an essentially free field over a reflecting plane (ISO 11201:1995)

identification of all significant hazards associated with the machine. Table 1 — List of significant hazards associated with walk-behind trimmers Ref. No.
Hazard Location
Reference of this European Standard 1 Mechanical hazards due to: 1.1 Inadequacy of mechanical strength Guards, cutting head
5.13 1.2 Shearing hazard Moving parts 5.1, 5.2.2, Annex F 1.3 Cutting or severing hazard Moving parts and cutting means 5.1, 5.2.2, 5.2.3, 5.9, 5.12, 6.1, 6.2, Annex D, Annex F 1.4 Entanglement hazard Moving parts 5.1, 5.2.2, 5.2.3, 5.12, 6.1, 6.2, Annex F 1.5 Impact hazard Thrown objects 5.2.3 2
Electrical hazards due to: 2.1 Contact of persons with live parts under high voltage (direct or indirect contact) Live parts 5.7.1, 5.7.4, 5.7.5 2.2 Projection of molten particles and chemical effects from short circuits, overloads, etc. Electric circuits 5.7.3 3 Thermal hazards such as burns by a possible contact of persons with engine exhaust parts with a high temperature,
Hot exhaust parts 5.2.4 4 Hazards generated by noise such as hearing loss (deafness), other physiological disorders (e.g. loss of balance, loss of awareness), and interference with auditory signals and speech communication Engine, transmission, cutting means 5.11, 6.1, 6.2, Annex B, Annex C, Annex F 5 Hazards generated by vibration such as the use of hand-held machines resulting in a variety of neurological and vascular disorders Handles 5.10, 6.1, Annex A

Hazard Location
Reference of this European Standard 6 Hazards generated by materials and substances
Engine exhaust
5.3,
6.1
Battery
5.4, 5.7.2 6.1 Hazards from contact with or inhalation of harmful fluids, gases, mists, fumes, and dusts Fuel 5.4, 5.5, 6.1
6.2 Fire or explosion hazard Fuel 5.4, 5.5, 5.7.1, 6.1, Annex F 7 Hazards generated by neglecting ergonomic principles in machinery design
Controls 5.6 7.1 Consideration of hand-arm or foot-leg anatomy Handles 5.9 7.2 Neglected use of personal protection equipment Eyes and ears 6.1, Annex F 7.3 Human error, human behaviour Guards 5.2 7.4 Unauthorised start-up/use Removable key 5.8 7.5 Inadequate design, location or identification of manual controls Controls 5.6 Cutting means control 5.6, 6.2 8 Hazards due to unexpected start-up, unexpected over-run
Engine stopping 5.7.4, 5.8 Cutting means 5.12 9 Hazards due to break-up during operation Cutting head 5.13.3, 6.2.3 10 Hazards due to insufficient instructions for the driver/operator Instructions for use 6.1, 6.2, Annex E, Annex F 5 Safety requirements and/or measures and means of verification 5.1 General Trimmers shall comply with the safety requirements and/or protective measures of this clause. In addition, the trimmer shall be designed according to the principles of EN ISO 12100 for relevant but not significant hazards, which are not dealt with by this European Standard. 5.2 Guards 5.2.1 General It shall not be possible to fit or adjust any guard required by this European Standard so that it does not comply with the requirements of this European Standard. Compliance shall be checked by inspection. 5.2.2 Power driven components (other than the cutting means) All power driven transmission parts shall be guarded to prevent the operator's contact with these parts. All guards required by this European Standard shall be fixed guards as defined in 3.25.1 of EN 12100-1:2003 or the construction of the trimmer shall be such that it cannot be used without the guard in its guarding position as defined in 3.25.4 of EN 12100-1:2003. All apertures and safety distances shall conform to 4.5.1, 4.5.3 and Table 4 of EN 294:1992. Compliance shall be checked by inspection.

textile reinforced rubber;  thickness
2 mm;  specific gravity
1,65;  hardness
70 Shore A;  tensile strength
3 MPa;  elongation
300 %;  temperature range - 20 °C to + 70 °C;  tear strength
15 N/mm2. Compliance shall be checked by inspection and measurement.

1) This subclause will be reviewed when the work on EN 14930:2007 is complete.
...
