EN 13859-2:2004

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Hidroizolacijski trakovi - Definicije in lastnosti podložnih folij - 2. del: Podložne folije za steneAbdichtungsbahnen - Definitionen und Eigenschaften von Unterdeck- und Unterspannbahnen - Teil 2: Unterdeck- und Unterspannbahnen für WändeFeuilles souples d'étanchéité - Définitions et caractéristiques des écrans souples - Partie 2: Ecrans souples pour murs extérieursFlexible sheets for waterproofing - Definitions and characteristics of underlays - Part 2: Underlays for walls91.100.50Veziva. Tesnilni materialiBinders. Sealing materials91.060.10Stene. Predelne stene. FasadeWalls. Partitions. Facades01.040.91Gradbeni materiali in gradnja (Slovarji)Construction materials and building (Vocabularies)ICS:Ta slovenski standard je istoveten z:EN 13859-2:2004SIST EN 13859-2:2005en01-maj-2005SIST EN 13859-2:2005SLOVENSKI
STANDARD
EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 13859-2December 2004ICS 01.040.91; 91.100.50English versionFlexible sheets for waterproofing - Definitions and characteristicsof underlays - Part 2: Underlays for wallsFeuilles souples d'étanchéité - Définitions etcaractéristiques des sous-couches - Partie 2: Sous-couches pour murs et cloisons extérieursAbdichtungsbahnen - Definitionen und Eigenschaften vonUnterdeck- und Unterspannbahnen - Teil 2: Unterdeck- undunterspannbahnen für WändeThis European Standard was approved by CEN on 20 October 2004.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the Central Secretariat or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the Central Secretariat has the same status as the officialversions.CEN members are the national standards bodies of Austria, Belgium, Cyprus, Czech Republic, Denmark, Estonia, Finland, France,Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Slovakia,Slovenia, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre: rue de Stassart, 36
B-1050 Brussels© 2004 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 13859-2:2004: ESIST EN 13859-2:2005

Determination of tensile properties.13 Annex B (normative)
Determination of resistance to tearing.16 Annex C (normative)
Artificial ageing by exposure to UV and heat.18 SIST EN 13859-2:2005

Initial type test and frequencies of testing for factory production control.21 Annex E (informative)
Example of a product data sheet.23 Annex ZA (informative)
Clauses of this European Standard addressing provision of the Construction Products Directive (CPD).25 Bibliography.32
— Part 1: Bitumen sheets for roof waterproofing — Determination of dimensional stability EN 1107-2, Flexible sheets for waterproofing — Determination of dimensional stability — Part 2: Plastic and rubber sheets for roof waterproofing EN 1109, Flexible sheets for waterproofing — Bitumen sheets for roof waterproofing — Determination of flexibility at low temperature EN 1296, Flexible sheets for waterproofing — Bitumen, plastic and rubber sheets for roofing — Method of artificial ageing by long term exposure to elevated temperature EN 1297, Flexible sheets for waterproofing — Bitumen, plastic and rubber sheets for roof waterproofing — Method of artificial ageing by long term exposure to the combination of UV radiation, elevated temperature and water EN 1848-1, Flexible sheets for waterproofing — Determination of length, width, and straightness — Part 1: Bitumen sheets for roof waterproofing EN 1848-2, Flexible sheets for waterproofing — Determination of length, width, straightness and flatness — Part 2: Plastic and rubber sheets for roof waterproofing EN 1849-1, Flexible sheets for waterproofing — Determination of thickness and mass per unit area — Part 1: Bitumen sheets for roof waterproofing EN 1849-2, Flexible sheets for waterproofing — Determination of thickness and mass per unit area — Part 2: Plastic and rubber sheets for roof waterproofing EN 1928:2001, Flexible sheets for waterproofing — Bitumen, plastic and rubber sheets for roof waterproofing — Determination of watertightness EN 1931, Flexible sheets for waterproofing — Bitumen, plastic and rubber sheets for roof waterproofing — Determination of water vapour transmission properties EN 12114, Thermal performance of buildings — Air permeability of building components and building elements — Laboratory test method EN 12310-1:1999, Flexible sheets for waterproofing — Part 1: Bitumen sheets for waterproofing — Determination of resistance to tearing (nail shank) EN 12311-1, Flexible sheets for waterproofing — Part 1: Bitumen sheets for roof waterproofing — Determination of tensile properties SIST EN 13859-2:2005

4.3 Application related characteristics 4.3.1 Reaction to fire Where required, the reaction to fire shall be determined in accordance with 5.2.2. 4.3.2 Resistance to water penetration 4.3.2.1 Class W1 The product shall be classified as resistant to water penetration Class W1 if it passes the resistance to water penetration test in accordance with 5.2.3. If the product fails the test of resistance to water penetration indicated in 5.2.3, it shall be tested in accordance with 4.3.2.2. 4.3.2.2 Class W2 A product failing to pass the test indicated in 5.2.3 shall be tested in accordance with 5.2.4. If the measured mean volume of water passing through the specimens tested is less than 100 ml, the product shall be classified as resistant to water penetration Class W2. 4.3.2.3 Class W3 If the product fails the test indicated in 4.3.2.2, e.g. the measured mean volume passing the specimens exceeds 100 ml, it shall be classified as resistant to water penetration Class W3. Untested products shall also be classified as resistant to water penetration Class W3. 4.3.3 Water vapour transmission properties The product shall be tested in accordance with 5.2.5 and the results shall lie within the declared tolerance of the manufacturer’s declared value. Other measuring methods shall also be allowed if the correlation with 5.2.5 is proved and recorded. If the water vapour diffusion-equivalent air layer thickness sd is above or equal to SIST EN 13859-2:2005
...
