EN 3773-004:2014
(Main)Aerospace series - Circuit breakers, single-pole, temperature compensated, rated currents 1 A to 25 A - Part 004: UNC thread terminals - Product standard
Aerospace series - Circuit breakers, single-pole, temperature compensated, rated currents 1 A to 25 A - Part 004: UNC thread terminals - Product standard
This European Standard specifies the characteristics of single-pole circuit breakers, temperature compensated with a rated current from 1 A to 25 A, used in aircraft on-board circuits at a temperature between – 55 °C and 125 °C and at an altitude of 22 000 m max.
These circuit breakers are operated by a push-pull type single push button (actuator), with delayed action "trip-free" tripping.
They will continue to function up to the short-circuit current.
Luft- und Raumfahrt - Schutzschalter, einpolig, temperaturkompensiert, Nennströme von 1 A bis 25 A - Teil 004: UNC-Klemmengewinde - Produktnorm
Série aérospatiale - Disjoncteurs unipolaires compensés en température, intensités nominales 1 A à 25 A - Partie 004 : Bornes à filetage UNC - Norme de produit
Aeronavtika - Odklopniki, enopolni, temperaturno kompenzirani, naznačeni tok od 1 A do 25 A - 004. del: UNC-navojni priključki - Standard za proizvod
Ta evropski standard določa značilnosti enopolnih temperaturno kompenziranih odklopnikov z naznačenim tokom od 1 A do 25 A, ki se uporabljajo v letalskih vezjih pri temperaturi med –55 °C in 125 °C ter na največji višini 22000 m.
Ti odklopniki se upravljajo z enim gumbom (sprožilom) vrste potisni-povleci, z zakasnjenim proženjem brez sprožila.
Delovali bodo do kratkega stika.
