EN 1870-13:2007

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Sicherheit von Holzbearbeitungsmaschinen - Kreissägemaschinen - Teil 13: Horizontale Plattenkreissägemaschinen mit DruckbalkenSécurité des machines pour le travail du bois - Machines a scier circulaires - Partie 13: Scies a panneaux horizontales a presseurSafety of woodworking machines - Circular sawing machines - Part 13: Horizontal beam panel sawing machines79.120.10Lesnoobdelovalni strojiWoodworking machines25.080.60Strojne žageSawing machinesICS:Ta slovenski standard je istoveten z:EN 1870-13:2007SIST EN 1870-13:2008en,fr01-marec-2008SIST EN 1870-13:2008SLOVENSKI
STANDARDSIST EN 1870-2:2000/AC:2004SIST EN 1870-2:20001DGRPHãþD

EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 1870-13December 2007ICS 79.120.10Supersedes EN 1870-2:1999
English VersionSafety of woodworking machines - Circular sawing machines -Part 13: Horizontal beam panel sawing machinesSécurité des machines pour le travail du bois - Machines àscier circulaires - Partie 13: Scies à panneaux horizontalesà presseurSicherheit von Holzbearbeitungsmaschinen -Kreissägemaschinen - Teil 13: HorizontalePlattenkreissägemaschinen mit DruckbalkenThis European Standard was approved by CEN on 21 October 2007.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the CEN Management Centre or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as theofficial versions.CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland,France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal,Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre: rue de Stassart, 36
B-1050 Brussels© 2007 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 1870-13:2007: ESIST EN 1870-13:2008

Use of well tried components.53 Annex B (normative)
Impact test method for guards.54 B.1 General.54 B.2 Test method.54 SIST EN 1870-13:2008

Saw spindle dimensional tolerances.57 Annex D (normative)
Rigidity test for sectional safety curtain material.58 Annex E (normative)
Braking tests.60 E.1 Conditions for all tests.60 E.2 Tests.60 E.2.1 Un-braked run-down time.60 E.2.2 Braked run-down time.60 Annex F (normative)
Use of electronic components.61 F.1 General.61 F.2 SRECS design.61 F.2.1 Components, hardware.61 F.2.2 Safety related software.62 Annex ZA (informative)
Relationship between this European Standard and the Essential Requirements of EU Directive 98/37/EC.64 Bibliography.67
1 Scope This document deals with the significant hazards, hazardous situations and events as listed in Clause 4 which are relevant to horizontal beam panel sawing machines where the saw unit is mounted below the workpiece support and which are manually or mechanically loaded and / or unloaded, fitted with:  a side pressure device and / or  the facility for scoring and / or  the facility for post-formed / soft-formed edge pre-cutting and / or  a panel turning device and / or  a pushing out device and / or  pneumatic clamping of the saw blade and / or  a powered panel loading device and / or  a grooving device and / or  additional cutting line(s) inside the machine for longitudinal and / or head cut (before transversal cutting line) and / or  workpiece vacuum clamping as part of a panel turning device or of a panel loading device, hereinafter referred to as "machines" when they are used as intended and under the conditions foreseen by the manufacturer. The machines are designed for cutting panels consisting of: a) wood based materials such as chipboard, fibreboard, plywood and also these materials where they are covered with plastic/light alloy laminates which can be cut easily; b) solid wood; c) hardened rubber and hardened plastic material; d) non ferrous materials e.g. light alloy; e) gypsum boards, gypsum bounded fibreboards; f) composite boards made from the materials listed above. This document does not deal with specific hazards related to: i) specific features which differ from the list above; ii) the machining of panels with grooving tools; iii) mechanical unloading of panels; iv) the combination of a single machine being used with any other machine (as part of a line). SIST EN 1870-13:2008

Part 2: Immunity EN 60204-1:2006, Safety of machinery — Electrical equipment of machines — Part 1: General requirements (IEC 60204-1:2005, modified) EN 60439-1:1999, Low-voltage switchgear and controlgear assemblies — Part 1: Type-tested and partially type-tested assemblies (IEC 60439-1:1999) EN 60529:1991, Degrees of protection provided by enclosures (IP Code) (IEC 60529:1989) EN 60825-1:1994, Safety of laser products — Part 1: Equipment classification, requirements and user’s guide (IEC 60825-1:1993) EN 61310-1:1995, Safety of machinery — Indication, marking and actuation — Part 1: Requirements for visual, auditory and tactile signals (IEC 61310-1:1995) EN 61496-1:2004, Safety of machinery — Electro−sensitive protective equipment — Part 1: General requirements and tests (IEC 61496-1: 2004, modified) CLC/TS 61496-2:2006, Safety of machinery — Electro-sensitive protective equipment — Part 2: Particular requirements for equipment using active opto-electronic protective devices (AOPDs) (IEC 61496-2:2006) EN 61508-3:2001, Functional safety of electrical/electronic/programmable electronic safety-related systems — Part 3: Software requirements (IEC 61508-3:1998 + Corrigendum:1999) EN 62061:2005, Safety of machinery — Functional safety of safety-related electrical, electronic and programmable electronic control systems (IEC 62061:2005) EN ISO 3743-1:1995, Acoustics — Determination of sound power levels of noise sources — Engineering methods for small movable sources in reverberant fields — Part 1: Comparison method for hard-walled test rooms (ISO 3743-1:1994) EN ISO 3743-2:1996, Acoustics — Determination of sound power levels of noise sources using sound pressure — Engineering methods for small, movable sources in reverberant fields — Part 2: Methods for special reverberant test rooms (ISO 3743-2:1994) EN ISO 3744:1995, Acoustics — Determination of sound power levels of noise sources using sound pressure — Engineering method in an essentially free field over a reflecting plane (ISO 3744:1994) EN ISO 3745:2003, Acoustics — Determination of sound power levels of noise sources using sound pressure — Precision methods for anechoïc and semi-anechoïc rooms (ISO 3745:2003) EN ISO 3746:1995, Acoustics — Determination of sound power levels of noise sources using sound pressure — Survey method using an enveloping measurement surface over a reflecting plane (ISO 3746:1995) EN ISO 4871:1996, Acoustics — Declaration and verification of noise emission values of machinery and equipment (ISO 4871:1996) EN ISO 9614-1:1995, Acoustics — Determination of sound power levels of noise sources using sound intensity — Part 1: Measurements at discrete points (ISO 9614-1:1993) EN ISO 11202:1995, Acoustics — Noise emitted by machinery and equipment — Measurement of emission sound pressure levels at the work station and at other specified positions — Survey method in situ
(ISO 11202:1995) EN ISO 11204:1995, Acoustics — Noise emitted by machinery and equipment — Measurement of emission sound pressure levels at the work station and at other specified positions — Method requiring environmental corrections (ISO 11204:1995) SIST EN 1870-13:2008

Figure 1 a) — Example of a horizontal beam panel saw with panel loading from the rear side by a powered loading device and with fixed distance guarding and light barrier SIST EN 1870-13:2008

Figure 1 b) — Example of a horizontal beam panel saw with panel loading from the front side and with fixed distance guarding SIST EN 1870-13:2008

Figure 1 c) — Example of a horizontal beam panel saw with panel loading from the front and with individual safeguarding of hazardous points Figure 1 — Examples of horizontal beam panel saws
Key 1 front cutting line 2 longitudinal cutting line 3 head cutting line Figure 2 — Horizontal beam panel saw cutting lines
3.2 integrated feed feed mechanism for the workpiece and the saw unit(s) incorporating the saw blade(s) which are integrated with the machine and where the workpiece and the saw unit(s) are held and controlled mechanically during the machining operation 3.3 manual loading where the operator puts the workpiece on the workpiece support from the front side of the machine i.e. there is no intermediate loading device to transfer the workpiece from the operator to the machine front cutting line 3.4 manual unloading where the operator removes the workpiece from the workpiece support i.e. there is no intermediate unloading device to transfer the workpiece from the cutting position to the operator within 1 500 mm 3.5 powered loading where the workpiece(s) is / are put on the workpiece support by e.g. a lifting unit or a loading device, normally a lifting platform SIST EN 1870-13:2008

Key 1 post-formed / soft-formed edge pre-cutting saw blade 2 feed direction of the saw unit 3 movement of post-formed / soft-formed edge pre-cutting saw blade 4
main saw blade
Figure 3 — Post-formed / soft-formed edge pre-cutting 3.12 post-formed / soft-formed edge pre-cutting saw blade saw blade used for post-formed edge pre-cutting. This may be the scoring saw blade or a separate saw blade specifically for this purpose 3.13 saw blade rest position position to which the saw blade(s) return(s) at the end of the cut outside the cutting area i.e. into a position below the workpiece support or together with the saw unit into a position outside the cutting area also with protruding saw blade(s) 3.14 saw unit rest position position to which the saw unit returns at the end of each cutting cycle 3.15 pressure beam rest position position to which the pressure beam returns after the saw blade(s) has/have reached its/their rest position 3.16 cutting cycle movements of the saw unit incorporating the saw blade during the machining operation comprising:  movement of the saw blade from its rest position to the cutting position;  movement of the saw unit from its cutting position through the cutting stroke; SIST EN 1870-13:2008

No Hazards, hazardous situations and hazardous events
EN ISO 12100
Relevant clause of this document
Part 1:2003 Part 2:2003
1 Mechanical hazards related to: - machine parts or workpieces due to:
a) shape; 5.2.2, 5.3.3, 5.3.5, 5.3.6, 6.2, 6.3, Annex C
b) relative location; 5.2.2, 5.2.3, 5.2.6, 5.3.6, 6.2
c) mass and stability (potential energy of elements which may move under the effect of gravity); 5.2.6, 5.2.8
d) mass and velocity (kinetic energy of elements in controlled or uncontrolled motion); 5.2.3, 5.2.6, 5.3.5, 5.3.6
e) mechanical strength; 4.2 4.2.1, 4.2.2, 5
5.3.2, Annex B, Annex D
- accumulation of energy inside the machinery by:
f) gases under pressure; 4.2 4.10, 5.5.4 5.4.6 1.1 Crushing hazard 5.2.3, 5.2.4, 5.2.6, 5.3.4, 5.3.5, 5.3.6, 5.3.7, 5.4.11, 5.4.12 1.2 Shearing hazard 5.2.3, 5.2.4, 5.3.4, 5.3.5, 5.3.6, 5.3.7, 5.4.11, 5.4.12 1.3 Cutting or severing hazard 5.2.3, 5.2.4, 5.2.5, 5.2.6, 5.3.4, 5.3.6, 5.3.7, 5.4.11, 5.4.12 1.4 Entanglement hazard 5.2.4, 5.2.5, 5.3.6, 5.3.7, 5.4.11, 5.4.12 1.5 Drawing-in or trapping hazard 5.2.3, 5.2.4, 5.2.5, 5.3.4, 5.3.6, 5.3.7, 5.4, 11, 5.4.12 1.6 Impact hazard 5.2.3, 5.3.5, 5.4.11 1.9 High pressure fluid injection or ejection hazard 4.2.1
5.2.4, 5.3.5, 5.4.7, 5.4.11 SIST EN 1870-13:2008

2 Electrical hazards due to: 2.1 Contact of persons with live parts (direct contact) 4.3 4.9, 5.5.4
5.4.4, 5.4.11 2.2 Contact of persons with parts which have become live under faulty conditions (indirect contact) 4.3 4.9
5.4.4, 5.4.11 2.4 Electrostatic phenomena 4.3 4.9
5.4.8 4 Hazards generated by noise, resulting in: 4.1 Hearing loss (deafness), other physiological disorders (loss of balance, loss of awareness) 4.5 4.2.2, 5
5.4.2 4.2 Interference with speech communication, acoustic signals
6.3 6 Hazards generated by radiation 6.5 Laser 4.7
5.4.10 7 Hazards generated by materials and substances (and their constituent elements) processed or used by the machinery 7.1 Hazards from contact with or inhalation of harmful fluids and dusts 4.8 4.3b, 4.4 5.4.3, 6.3 7.2 Fire
4.8 4.4
5.4.1 8 Hazards generated by neglecting ergonomic principles in machinery design: 8.1 Unhealthy postures or excessive effort 4.9 4.7, 4.8.2, 4.11.12, 5.5.5, 5.5.6 5.2.2, 5.4.5 8.2 Hand-arm or foot-leg anatomy 4.9 4.8.3 5.4.5 8.4 Local lighting
4.8.6 6.3 8.5 Mental overload and underload, stress 4.9 4.8.5 6.3 8.6 Human error, human behaviour 4.9 4.8, 4.11.8, 4.11.10, 5.5.2, 6 6.3 8.7
Design, location or identification of manual controls
4.8.7, 4.11.8
5.2.2 8.8 Design or location of visual display units
4.8.8, 6.2
5.2.2 9 Combination of hazards 4.11
5.2.3, 5.2.5, 5.2.6, 5.2.7, 5.2.9, 5.3.6, 5.4.11, 5.4.12 10 Unexpected start-up, unexpected overrun/overspeed (or any similar malfunction) from: 10.1 Failure / disorder of the control system
4.11, 5.5.4
5.2.1, 5.2.9, 5.4.11 10.2 Restoration of energy supply after an interruption
4.11.4
5.2.8, 5.4.6 10.3 External influences on electrical equipment
4.11.11
5.4.7, Annex F 10.4 Other external influences (gravity)
5.3.5 10.5 Errors in the software
4.11.7 Annex F 10.6 Errors made by the operator (due to mismatch of machinery with human characteristics and abilities, see 8.6) 4.9 4.8, 4.11.8, 4.11.10, 5.5.2, 6
6.3 (to be continued)SIST EN 1870-13:2008

Table 1 — List of significant hazards (concluded)
No Hazards, hazardous situations and hazardous events
EN ISO 12100
Relevant clause of this document
Part 1: 2003 Part 2: 2003
11 Impossibility of stopping the machine in the best possible conditions
4.11.1, 4.11.3, 5.5.2
5.2.4, 5.2.5, 5.4.11 12 Variations in the rotational speed of tools
4.2.2, 4.3 5.2.7 13 Failure of the power supply
4.11.1, 4.11.4
5.2.8 14 Failure of the control circuit
4.11, 5.5.4
5.2.9 15 Errors of fitting 4.9
4.7, 6.5
5.4.9 16 Break-up during operation 4.2.2 4.3
5.3.2 17 Falling or ejected objects or fluids 4.2.2 4.3, 4.10
5.2.6, 6.3 18 Loss of stability / overturning of machinery 4.2.2 5.2.6
5.3.1
5 Safety requirements and / or measures 5.1 General The machine shall comply with the safety requirements and / or protective measures of Clauses 5 and 6. NOTE 1 In addition, the machine should be designed according to the principles of EN ISO 12100-1:2003 and
EN ISO 12100-2:2003 for hazards relevant but not significant, which are not dealt with by this document (e.g. sharp edges of the machine frame). NOTE 2 For guidance in connection with risk reduction by design see Clause 4 of EN ISO 12100-2:2003 and for safeguarding measures see Clause 5 of EN ISO 12100-2:2003. 5.2 Controls 5.2.1 Safety and reliability of control systems 5.2.1.1 General For the purpose of this document safety related part of a control system means the system from the initial device, e.g. push button or position detector or sensor up to and including the power control element of the final machine actuator or element, e.g. motor or brake. Safety related parts of the control system of this machine comprise parts concerning the following functions and they shall fulfil the requirements of the categories given below according to EN ISO 13849-1:2006: a) for starting and restarting and for prevention of unexpected start-up after failure of power supply: category 1 or 3 (see 5.2.3, 5.2.8); b) for normal stopping: category 1 or 3 (see 5.2.4); SIST EN 1870-13:2008
...
