Key 1 Buffer 2 Primary coating 3 Cladding 4 Core Figure 1 — Fibre construction (axial view) 4.4 Cable construction The typical requirements of the cable shall be an outer jacket, strength member, buffer and fibre, which is protected by a primary coating. See example at Figure 2. Details of the materials used for the outer sheath, strength member, inner sheath and buffer shall be defined in the product standard. 1234SIST EN 4641-001:2009

Key 1 Outer jacket 2 Strength member 3 Inner sheath 4 Buffer 5 Core 6 Cladding 7 Primary coating Figure 2 — Example of cable construction 5 Test methods 5.1 Tests in accordance with EN 3745-100 5.1.1 Optical fibre See Table 1. Table 1 — Optical fibre test methods Test method EN 3745- Designation of test Test performance/conditions/criteria 201 Visual examination The primary coating and buffer shall have the correct identification outer colour if specified in the product standard. 202 Fibre dimensions See product standard. 501 Optical fibre proof test See product standard. 301 Method A Attenuation See product standard. 302 Numerical aperture See product standard. 403 Bandwidth See product standard.
1234567SIST EN 4641-001:2009
...
