ASTM D2913-20

This document is not an ASTM standard and is intended only to provide the user of an ASTM standard an indication of what changes have been made to the previous version. Because
it may not be technically possible to adequately depict all changes accurately, ASTM recommends that users consult prior editions as appropriate. In all cases only the current version
of the standard as published by ASTM is to be considered the official document.
Designation: D2913 − 14 D2913 − 20
Standard Test Method for
Mercaptan Content of the Atmosphere
This standard is issued under the fixed designation D2913; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
1. Scope
1.1 This test method is for the measurement of mercaptans (organic thiols) in the atmosphere at concentrations below 100 parts
per billion (ppb(v) = 195 μg/m ). For concentrations above 100 ppb(v), the sampling period can be reduced or the trapping liquid
volume increased either before or after aspirating. (See Practice D1357 for sampling guidance.) The minimum detectable amount
of methyl mercaptan is 0.04 μg/mL (1) in a final liquid volume of 25 mL. When sampling air at the maximum recommended rate
of 2 L/min for 2 h, the minimum detectable mercaptan concentration is 1.0 ppb(v) (1.95 μg methyl mercaptan/m at 101.3 kPa (760
mm Hg) and 25°C). This test method determines total mercaptans and does not differentiate among individual mercaptans,
although it is most sensitive to the lower molecular weight alkanethiols.
1.2 The values stated in SI units are to be regarded as standard. No other units of measurement are included in this standard.
1.3 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility
of the user of this standard to establish appropriate safety safety, health, and healthenvironmental practices and determine the
applicability of regulatory limitations prior to use. Specific precautionary statements are given in 8.7, 8.8, and Section 9.
1.4 This international standard was developed in accordance with internationally recognized principles on standardization
established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued
by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
2. Referenced Documents
2.1 ASTM Standards:
D1193 Specification for Reagent Water
D1356 Terminology Relating to Sampling and Analysis of Atmospheres
D1357 Practice for Planning the Sampling of the Ambient Atmosphere
D1914 Practice for Conversion Units and Factors Relating to Sampling and Analysis of Atmospheres
D2914 Test Methods for Sulfur Dioxide Content of the Atmosphere (West-Gaeke Method)
D3195 Practice for Rotameter Calibration
D3249 Practice for General Ambient Air Analyzer Procedures
D3609 Practice for Calibration Techniques Using Permeation Tubes
D3631 Test Methods for Measuring Surface Atmospheric Pressure
E2251 Specification for Liquid-in-Glass ASTM Thermometers with Low-Hazard Precision Liquids
This test method is under the jurisdiction of ASTM Committee D22 on Air Quality and is the direct responsibility of Subcommittee D22.03 on Ambient Atmospheres
and Source Emissions.
Current edition approved Sept. 1, 2014Sept. 1, 2020. Published October 2014September 2020. Originally approved in 1970. Last previous edition approved in 20072014
as D2913 – 96 (2007).D2913 – 14. DOI: 10.1520/D2913-14.10.1520/D2913-20.
The boldface numbers in parentheses refer to a list of references at the end of this standard.
For referenced ASTM standards, visit the ASTM website, www.astm.org, or contact ASTM Customer Service at service@astm.org. For Annual Book of ASTM Standards
volume information, refer to the standard’s Document Summary page on the ASTM website.
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
D2913 − 20
3. Terminology
3.1 Definitions—For definitions of terms used in this test method, refer to Terminology D1356.
4. Summary of Test Method
4.1 This test method is intended for obtaining an integrated sample over a selected time span (such as 2 h) either manually or in
an automatic sequential sampler using 10 mL of absorption liquid in a bubbler.
4.2 The absorption liquid is delivered to the laboratory for colorimetric analysis by reaction between the collected mercaptan and
N,N-dimethyl-p-phenylenediamine.
5. Significance and Use
5.1 Mercaptans are odorous substances offensive at low concentrations and toxic at higher levels. They are emitted from
geothermal sources, industrial processes, and food processing facilities. Mercaptans at low concentrations are commonly added to
natural gas and LP gases for safety purposes as well.
6. Interferences
6.1 The N,N-dimethyl-p-phenylenediamine reaction is also used in the determination of other sulfur-containing compounds
including hydrogen sulfide and dimethyl disulfide (2). The potential for interference from these latter compounds is especially
important, since all of these compounds commonly coexist in certain industrial emissions. Appropriate selection of the color
formation conditions and measurements of absorbance at the specified wavelength will eliminate the potential interference from
hydrogen sulfide.
6.2 Hydrogen sulfide, if present in the sampled air, may cause a turbidity in the sample absorbing solution. This precipitate must
be filtered before proceeding with the analysis. One study showed that 100 μg of H S gave a mercaptan color equivalent to 1.5
to 2.0 μg of mercaptan (3). Another study reported no absorption at 500 nm in the presence of 150 μg of hydrogen sulfide (4, 5).
6.3 Approximately equimolar response is obtained from the hydrolysis products of dimethyl disulfide, the molar extinction
coefficient for the amine-mercaptan reaction product being 4.4 × 10 , and the amine-dimethyl disulfide reaction product being
5.16 × 10 (5). The interference due to dimethyl disulfide has been experimentally determined. Dimethyl disulfide concentrations
of 0.6 ppm(v) and 1.0 ppm(v) given an equivalent response as 0.4 ppm(v) and 0.8 ppm(v), respectively, of methyl mercaptan.
6.4 Sulfur dioxide up to 250 μg does not influence the color development even when sampling a test atmosphere containing 300
ppm(v) of SO .
6.5 Nitrogen dioxide does not interfere up to 700 μg of NO when sampling a test atmosphere containing 6 ppm mercaptans.
Higher concentrations of NO caused a positive interference when mercaptans were present, but no interference in the absence of
mercaptans. Such elevated NO concentrations are not commonly encountered in ambient air except in the vicinity of an accidental
spillage.
6.6 The supply of mercuric acetate must be free of mercurous ion. If mercurous ion is present, turbidity will result when the
chloride ion-containing reagents are added in the last step of the analytical procedure.
7. Apparatus
7.1 Sampling Apparatus:
7.1.1 Absorber—Midget bubbler with coarse porosity frit.
Supporting data giving the results of a laboratory examination of this method by the National Council of the Paper Industry for Air and Stream Improvement (NCASI)
are available in special report No. 80-07, “A Laboratory Examination of the Use of the ASTM/APHA. Spectrophotometric Method for the Measurement of Methyl Mercaptan
in Kraft Mill Workspace Atmospheres,” May 1980, NCASI, 260 Madison Ave., New York, NY 10016.
D2913 − 20
7.1.2 Air Sample Probe—TFE-fluorocarbon, polypropylene, or glass tube with a polypropylene or glass funnel at the end.
7.1.3 Moisture Trap-Glass, or polypropylene tube with a two port closure. The entrance port of the closure is fitted with tubing
that extends to the bottom of the trap. The unit is loosely packed with 16-mesh activated charcoal to prevent moisture entrainment.
The charcoal should be changed at least weekly and more frequently when sampling high humidity air.
7.1.4 Filter—Membrane, of 0.8 to 2.0 μm porosity.
7.1.5 Pump—Capable of maintaining a vacuum greater than 70 kPA (0.7 atm) at the specified flowrate.
7.1.6 Flow Control Device—A needle valve capable of maintaining a constant flow rate (62 %). Protect the needle valve from
particulate matter and moisture entrainment.
7.1.7 Flow meter, having a range of 0 to 2.5 L/min.
7.1.8 Thermometers—Precision digital thermometers based on resistance temperature detectors (RTDs), thermistors,
thermocouples, or organic liquid-in-glass thermometers (such as Thermometer S18C in SpecificationsSpecification E2251)
meeting the requirements of specific applications in this method may be used.
7.1.9 Barograph or Barometer—Capable of measuring atmospheric pressure to 60.5 kPa (4 Torr), meeting the requirements of
Test Methods D3631.
7.1.10 Stopwatch or timer, accurate to 61 s/24 h.
7.1.11 The arrangements of the component parts of sampling is shown in Fig. 1a, Test Methods D2914.
7.2 Calibration Apparatus—A means of generating dynamic standard atmospheres using a permeation device. Dilution air and
excess dilution flow must be filtered through activated charcoal to prevent recirculating small quantities of mercaptans. See
Practice D3609 for details.
7.3 Colorimeter or Spectrophotometer, (at 500 nm)—Use 2.5- or 5.0-cm path length to obtain adequate sensitivity.
8. Reagents and Materials
8.1 Purity of Reagents—Reagent grade chemicals shall be used in all tests. All reagents shall conform to the specifications of the
Committee on Analytical Reagents of the American Chemical Society, where such specifications are available. Other grades may
be used, provided it is first ascertained that the reagent is of sufficiently high purity to permit its use without lessening the accuracy
of the determination.
8.2 Purity of Water—Unless otherwise indicated, references to water shall mean reagent water conforming to Specification D1193.
8.3 Solutions should be refrigerated when not in use.
8.4 Amine-Hydrochloric Acid Solution, Stock—Dissolve 5.0 g of N,N-dimethyl- p-phenylenediamine hydrochloride (p-
aminodimethylaniline hydrochloride) in 1 L of concentrated hydrochloric acid (HCl). Refrigerate at approximately 10°C and
protect from light. This solution is stable for at least 6 months.
8.5 R
...
