SIST EN IEC 63267-3-61:2025
(Main)Fibre optic interconnecting devices and passive components - Fibre optic connector optical interfaces for enhanced macrobend multimode fibres - Part 3-61: Connector parameters of physically contacting 50 μm core diameter fibres - Non-angled 2,5 mm and 1,25 mm diameter cylindrical full zirconia ferrules for reference connection applications (IEC 63267-3-61:2025)
Fibre optic interconnecting devices and passive components - Fibre optic connector optical interfaces for enhanced macrobend multimode fibres - Part 3-61: Connector parameters of physically contacting 50 μm core diameter fibres - Non-angled 2,5 mm and 1,25 mm diameter cylindrical full zirconia ferrules for reference connection applications (IEC 63267-3-61:2025)
IEC 63267-3-61: 2025 defines the dimensional limits of an optical interface for reference connectors with 2,5 mm or 1,25 mm diameter cylindrical zirconia (ZrO2) ferrules necessary to meet specific requirements for fibre-to-fibre interconnection of non-angled polished multimode reference connections as defined in IEC 63267-2-2. Ferrule dimensions and features are contained in the IEC 61754 series of fibre optic connector interface standards. One grade of reference connector, Rm1, is defined in this document. The reference connector is terminated to restricted IEC 60793-2-10 using A1-OM2b to A1‑OM5b fibre in 850 nm band only. The geometrical dimensions and tolerances of the specified reference connector have been developed primarily to limit the variation in measured attenuation between multiple sets of reference connectors, and therefore to reduce the variation in measured attenuation between an arbitrarily chosen reference connector when mated with a connector in the field or factory.
This first edition and the first edition of IEC 63267-2-2 cancel and replace the first edition of IEC 61755-6-2 published in 2018. This edition constitutes a technical revision. The document includes the following significant technical changes with respect to the previous edition:
a) Definition of a reference grade, Rm1 interface;
b) Inclusion of A1-OM2b to A1-OM5b fibres;
c) Updates to normative references;
d) The addition of Annex A, which describes the attenuation test limits of reference grade Rm1 connectors to grade Bm connectors;
e) A new Annex B that describes the allowable fibre undercut.
Lichtwellenleiter – Verbindungselemente und passive Bauteile – Optische Schnittstellen von Lichtwellenleiter-Steckverbindern für verbesserte Makrobend-Multimodefasern – Teil 3-61: Parameter von Steckverbindern mit physikalischem Kontakt für Fasern mit 50 µm Kerndurchmesser – Nicht abgeschrägte zylindrische Vollzirkoniumdioxid- Ferrulen mit 2,5 mm und 1,25 mm Durchmesser für Referenzanschlussanwendung (IEC 63267-3-61:2025)
Dispositifs d’interconnexion et composants passifs fibroniques - Interfaces optiques des connecteurs fibroniques pour fibres multimodales améliorées en macrocourbures - Partie 3-61: Paramètres de connexion des fibres d’un diamètre de cœur de 50 µm en contact physique - Ferrules cylindriques non inclinées en zircone pleine de 2,5 mm et 1,25 mm de diamètre, pour les applications de connexion de référence (IEC 63267-3-61:2025)
IEC 63267-3-61: 2025 définit les limites dimensionnelles d’une interface optique pour des connecteurs de référence dotés de férules cylindriques en zircone (ZrO2) de 2,5 mm ou 1,25 mm de diamètre, qui sont nécessaires pour satisfaire aux exigences spécifiques pour l’interconnexion fibre à fibre des connexions de référence multimodales polies et non inclinées, telles qu’elles sont définies dans l’IEC 63267-2-2. Les dimensions et les caractéristiques des férules sont spécifiées dans les normes d’interfaces de connecteurs fibroniques de la série IEC 61754. Le présent document définit une classe de connecteur de référence, Rm1. Le connecteur de référence est raccordé à une sélection de fibres conformes à l’IEC 60793-2-10, soit les fibres des sous-catégories A1-OM2b à A1‑OM5b, et uniquement dans la bande de 850 nm. Les dimensions géométriques et les tolérances du connecteur de référence spécifié ont été développées principalement pour limiter les écarts au niveau de l’affaiblissement mesuré entre les différents ensembles de connecteurs de référence, et donc pour réduire les écarts au niveau de l’affaiblissement mesuré sur un connecteur de référence choisi arbitrairement, lorsqu’il est accouplé à un connecteur sur le terrain ou en usine.
Cette première édition et la première édition de l'IEC 63267-2-2 annulent et remplacent la première édition de l'IEC 61755-6-2 parue en 2018. Cette édition constitue une révision technique. Le document inclut les modifications techniques majeures suivantes par rapport à l'édition précédente:
a) définition d'une classe de référence, interface Rm1;
b) inclusion des fibres A1-OM2b à A1-OM5b;
c) mise à jour des références normatives;
d) ajout de l'Annexe A, qui décrit les limites de l’essai d’affaiblissement des connecteurs de classe de référence Rm1 par rapport aux connecteurs de classe Bm;
e) nouvelle Annexe B qui décrit le retrait admissible de la fibre.
