SIST EN 302 885 V2.1.1:2016
(Main)Portable Very High Frequency (VHF) radiotelephone equipment for the maritime mobile service operating in the VHF bands with integrated handheld class D DSC -Harmonised Standard covering the essential requirements of articles 3.2 and 3.3(g) of the Directive 2014/53/EU
General Information
- Abstract
The present document states the minimum technical characteristics and methods of measurement required for portable
Very High Frequency (VHF) radiotelephones with integrated handheld class D DSC operating in certain frequency
bands allocated to the maritime mobile service using either 25 kHz channels or 25 KHz and 12,5 kHz channels.
The present document also specifies technical characteristics, methods of measurement and required test results.
The present document contains requirements to demonstrate that "... radio equipment shall be so constructed that it both
effectively uses and supports the efficient use of radio spectrum in order to avoid harmful interference" and that "....radio
equipment supports certain features ensuring access to emergency services" [i.5].
- Status
- Published
- Public Enquiry End Date
- 14-Mar-2016
- Publication Date
- 13-Apr-2016
- Technical Committee
- MOC - Mobile Communications
- Current Stage
- 6060 - National Implementation/Publication (Adopted Project)
- Start Date
- 08-Apr-2016
- Due Date
- 13-Jun-2016
- Completion Date
- 14-Apr-2016
Buy Documents
ETSI EN 302 885 V2.1.0 (2015-12) - Portable Very High Frequency (VHF) radiotelephone equipment for the maritime mobile service operating in the VHF bands with integrated handheld class D DSC; Harmonised Standard covering the essential requirements of articles 3.2 and 3.3(g) of the Directive 2014/53/EU
ETSI EN 302 885 V2.1.1 (2016-03) - Portable Very High Frequency (VHF) radiotelephone equipment for the maritime mobile service operating in the VHF bands with integrated handheld class D DSC; Harmonised Standard covering the essential requirements of articles 3.2 and 3.3(g) of the Directive 2014/53/EU
Overview
SIST EN 302 885 V2.1.1:2016 specifies the essential requirements and test procedures for portable Very High Frequency (VHF) radiotelephone equipment with integrated handheld class D Digital Selective Calling (DSC) used in the maritime mobile service. This harmonized European standard ensures that VHF radiotelephones operating in designated maritime bands-using 25 kHz and 12.5 kHz channels-comply with Articles 3.2 and 3.3(g) of Directive 2014/53/EU regarding effective spectrum use and support for emergency services.
By detailing minimum technical characteristics and methods of measurement, the standard helps manufacturers, regulatory bodies, and users ensure that marine handheld VHF radios are reliable, safe, and interoperable, supporting both daily communication and critical distress signaling.
Key Topics
The standard covers several important topics for maritime VHF radiotelephone equipment, including:
- Technical Requirements: Defines criteria for construction, controls, indicators, microphone, loudspeaker, and safety features.
- Operational Performance: Testing conditions for normal and extreme environments such as temperature, humidity, and drop resistance.
- Testing Methods: Specifies standardized methods for measuring critical parameters such as frequency error, transmitter power, audio quality, spurious emissions, sensitivity, selectivity, and squelch performance.
- Digital Selective Calling (DSC): Requirements for integrated class D DSC functionality, including support for distress signaling, alarm handling, emergency communication, and automated distress position updates via GNSS.
- Spectrum Efficiency and Interference Avoidance: Ensures equipment efficiently uses radio spectrum and minimizes the risk of harmful interference to other marine communication services.
- Access to Emergency Services: Mandates specific features for prompt access and reliable transmission of distress alerts and location information.
Applications
SIST EN 302 885 V2.1.1:2016 has broad practical applications within the maritime industry:
- Marine Safety and Rescue: Ensures handheld VHF radios with DSC can reliably transmit and receive communications for vessel safety and emergency assistance.
- Compliance for Manufacturers: Provides a clear set of technical criteria and testing procedures to develop and certify maritime VHF radiotelephone equipment sold in the European Union.
- Regulatory Conformance: Assists regulators and notified bodies in assessing radio equipment under the Radio Equipment Directive (RED) 2014/53/EU.
- Vessel Operators and Seafarers: Guarantees access to interoperable and effective VHF maritime communication tools, crucial for navigation, operational coordination, and distress situations.
- Maritime Training and Inspections: Supports standards-based training and equipment checks to ensure equipment readiness in safety audits and port inspections.
Related Standards
For comprehensive implementation and compliance, refer to additional relevant standards and references:
- ETSI EN 301 925: Maritime VHF radiotelephone equipment with DSC - general requirements.
- ITU-R M.493: Technical characteristics for DSC in maritime mobile services.
- IEC 60945: General requirements for marine navigation and radiocommunication equipment.
- Directive 2014/53/EU (RED): Legal framework for placing radio equipment on the EU market.
- IMO SOLAS: International Maritime Organization regulations for life-saving and communication equipment.
By adhering to SIST EN 302 885 V2.1.1:2016, marine equipment manufacturers and operators ensure that portable VHF radiotelephones deliver robust performance, spectrum efficiency, and essential safety features-supporting safe and effective maritime operations across Europe and beyond.
