European Standard (Telecommunications series)

Environmental Engineering (EE);
European telecommunication standard
for equipment practice;
Part 3: Engineering requirements for
miscellaneous racks and cabinets

2 ETSI EN 300 119-3 V2.1.1 (2004-09)

Reference
REN/EE-TMG005
Keywords
environment, rack, equipment practice
ETSI
650 Route des Lucioles
F-06921 Sophia Antipolis Cedex - FRANCE

Tel.: +33 4 92 94 42 00  Fax: +33 4 93 65 47 16

Siret N° 348 623 562 00017 - NAF 742 C
Association à but non lucratif enregistrée à la
Sous-Préfecture de Grasse (06) N° 7803/88

Important notice
Individual copies of the present document can be downloaded from:
http://www.etsi.org
The present document may be made available in more than one electronic version or in print. In any case of existing or
perceived difference in contents between such versions, the reference version is the Portable Document Format (PDF).
In case of dispute, the reference shall be the printing on ETSI printers of the PDF version kept on a specific network drive
within ETSI Secretariat.
Users of the present document should be aware that the document may be subject to revision or change of status.
Information on the current status of this and other ETSI documents is available at
http://portal.etsi.org/tb/status/status.asp
If you find errors in the present document, please send your comment to one of the following services:
http://portal.etsi.org/chaircor/ETSI_support.asp
Copyright Notification
No part may be reproduced except as authorized by written permission.
The copyright and the foregoing restriction extend to reproduction in all media.

© European Telecommunications Standards Institute 2004.
All rights reserved.
TM TM TM
DECT , PLUGTESTS and UMTS are Trade Marks of ETSI registered for the benefit of its Members.
TM
TIPHON and the TIPHON logo are Trade Marks currently being registered by ETSI for the benefit of its Members.
TM
3GPP is a Trade Mark of ETSI registered for the benefit of its Members and of the 3GPP Organizational Partners.
ETSI
3 ETSI EN 300 119-3 V2.1.1 (2004-09)
Contents
Intellectual Property Rights.4
Foreword.4
1 Scope.5
2 References.5
3 Dimensions for miscellaneous racks/cabinets.5
3.1 Height.5
3.2 Width.6
3.3 Depth.6
3.4 Other dimensions.6
4 Accessibility and line-up of miscellaneous racks/cabinets.6
5 Floor loading.6
5.1 Weight per unit area of fully equipped miscellaneous rack/cabinet .7
5.2 Weight per unit area of cable support structure and cabling .7
5.3 Point loading.7
6 Structural load on a miscellaneous rack/cabinet .7
6.1 Static load.7
6.2 Dynamic load.7
7 External cable access.7
8 Dimensions of packaged miscellaneous rack/cabinet .8
Annex A (informative): Illustrative figures.9
History .12

ETSI
4 ETSI EN 300 119-3 V2.1.1 (2004-09)
Intellectual Property Rights
IPRs essential or potentially essential to the present document may have been declared to ETSI. The information
pertaining to these essential IPRs, if any, is publicly available for ETSI members and non-members, and can be found
in ETSI SR 000 314: "Intellectual Property Rights (IPRs); Essential, or potentially Essential, IPRs notified to ETSI in
respect of ETSI standards", which is available from the ETSI Secretariat. Latest updates are available on the ETSI Web
server (http://webapp.etsi.org/IPR/home.asp).
Pursuant to the ETSI IPR Policy, no investigation, including IPR searches, has been carried out by ETSI. No guarantee
can be given as to the existence of other IPRs not referenced in ETSI SR 000 314 (or the updates on the ETSI Web
server) which are, or may be, or may become, essential to the present document.
Foreword
This European Standard (Telecommunications series) has been produced by ETSI Technical Committee Environmental
Engineering (EE).
The present document is part 3 of a multi-part deliverable aimed at setting out, on a common basis, the installation
engineering requirements for telecommunication practice, for housing equipment forming part of a public
telecommunications network.
EN 300 119-1 [1] is a general introduction and explains the terminology used. EN 300 119-2 [2] specifies the
engineering requirements for racks and cabinets. The present document specifies the engineering requirements for
miscellaneous racks and cabinets. EN 300 119-4 [3] covers engineering requirements for subracks in miscellaneous
racks and cabinets. EN 300 119-5 [4] covers the preferred thermal management solutions for subracks, racks/cabinets
and miscellaneous racks/cabinets installed indoors in restricted access locations, for the removal of heat dissipated by
one or more subracks in an rack complying to the requirements of this multi-part standard.
The present document applies to all telecommunication equipment forming part of the public telecommunications
network.
The present document is part 3 of a multi-part deliverable. Full details of the entire series can be found in part 1 [1].

National transposition dates
Date of adoption of this EN: 24 September 2004
Date of latest announcement of this EN (doa): 31 December 2004
Date of latest publication of new National Standard
or endorsement of this EN (dop/e): 30 June 2005
Date of withdrawal of any conflicting National Standard (dow): 30 June 2005

ETSI
5 ETSI EN 300 119-3 V2.1.1 (2004-09)
1 Scope
The present document details requirements for miscellaneous racks and cabinets supplied unequipped. The
miscellaneous racks/cabinets shall be used for housing telecommunication equipment forming part of a public
telecommunication network installed either on the public telecommunication operators' sites or in the premises of
operator's customers. The miscellaneous racks/cabinets shall be able to accommodate various equipments, e.g. subracks
(see EN 300 119-4 [3]) and shall have provision for doors or covers.
EN 300 119-1 [1] defines the meaning of rack or cabinet in the context of the present document.
