(Main)Modular units for machine tool construction — Support brackets
Modular units for machine tool construction — Support brackets
Specifies certain dimensions relating to the inerchangeability of support brackets used in special purpose machines constucted from modular units. Gives nominal size and designation.
Eléments standard pour la construction des machines-outils — Consoles
La présente Norme Internationale fixe certaines dimensions relatives à l'interchangeabilité des consoles utilisées pour la construction des machines spéciales à l'aide d'éléments standard.
General Information
- Status
- Published
- Publication Date
- 31-Aug-1976
- Technical Committee
- ISO/TC 39 - Machine tools
- Drafting Committee
- ISO/TC 39 - Machine tools
- Current Stage
- 9020 - International Standard under periodical review
- Start Date
- 15-Jan-2026
- Completion Date
- 15-Jan-2026
Overview
ISO 3610:1976, titled Modular Units for Machine Tool Construction - Support Brackets, is an international standard established by the International Organization for Standardization (ISO). This standard specifically defines the critical dimensions and interchangeability requirements for support brackets used in special purpose machines constructed from modular units. It provides nominal sizes and designations aimed at ensuring compatibility and standardization in machine tool building.
The standard was developed by ISO Technical Committee ISO/TC 39, which focuses on machine tools. It was first published in 1976 and has since gained wide international approval, playing a vital role in the modular construction of machine tool supports and brackets.
Key Topics
Interchangeability of Support Brackets
ISO 3610:1976 sets precise dimensional parameters to ensure that support brackets from different manufacturers or batches can be interchanged without compatibility issues, promoting modularity and flexibility.Nominal Sizes and Designations
The standard classifies support brackets by nominal widths corresponding to the widths of linear displacement tables. The five nominal sizes covered are:- 125 mm
- 160 mm
- 200 mm
- 250 mm
- 320 mm
Dimensional Specifications
Detailed dimensions, including bolt hole spacing, bracket length, width of bearing faces, and sizes of pass-through holes, are provided in millimeters. This precise dimensional guidance supports correct fitting and robust machine tool construction.Reference to Related ISO Standards
ISO 3610 references ISO 2562, which covers standard elements for machine tool construction, establishing a consistent framework across modular components.
Applications
ISO 3610:1976 is primarily applicable in the manufacturing and assembly of special purpose machines using modular construction methods. Typical applications include:
Machine Tool Building
Support brackets designed to ISO 3610 ensure that machine components can be assembled with interchangeable parts, reducing lead time and simplifying maintenance.Automation and Production Lines
In automated manufacturing systems that often require special fixtures or tooling, modular support brackets enhance the adaptability and scalability of the equipment.Custom Machinery Assembly
Manufacturers designing one-off or small batch machines benefit from the standardized bracket sizes facilitating easier sourcing and replacement.Maintenance and Repair Operations
Standardized support brackets allow for easier matching and replacement during machine maintenance, improving uptime and reducing costs.
Related Standards
ISO 2562: Modular Elements in Machine Tool Construction
Provides complementary dimensional tables and specifications for linear displacement tables, directly related to the nominal sizes designated in ISO 3610.ISO 9001: Quality Management Systems
Although not specific to bracket design, this standard is critical for manufacturers to ensure their products meet quality and consistency requirements.ISO 13399: Cutting Tool Data Representation and Exchange
Facilitates the integration of standardized modular components into machine tool data systems.
Benefits of Compliance
Adhering to ISO 3610:1976 delivers multiple practical benefits:
- Ensures compatibility and interchangeability of support brackets within the machine tool industry.
- Enables modular design, allowing for scalable, customizable machine construction.
- Supports streamlined manufacturing and maintenance processes through standardized dimensions.
- Promotes international trade and sourcing by harmonizing component specifications globally.
By following ISO 3610:1976, industries involved in machine tool construction gain a reliable framework for designing support brackets that fit seamlessly into modular assemblies-optimizing productivity and reducing engineering complexities.
