1 Scope This European Standard is applicable to railway vehicle driving cabs which are air-conditioned or heated/ventilated. These include:  locomotives;  mainline, suburban or regional vehicles;  urban vehicles such as metros and trams. This European Standard does not consider the special operational requirements of shunt locomotives. This European Standard specifies the comfort parameter measurement methods for driving cabs. The comfort parameters and their tolerances cited in this European Standard are defined in EN 14813-1. 2 Normative references The following referenced documents are indispensable for the application of this document. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. EN 14813-1:2006, Railway applications — Air conditioning for driving cabs — Part 1: Comfort parameters EN ISO 3381, Railway applications — Acoustics — Measurement of noise inside railbound vehicles (ISO 3381:2005) EN ISO 7726:2001, Ergonomics of the thermal environment — Instruments for measuring physical quantities (ISO 7726:1998) CIE 85, Solar spectral irradiance2) 3 Terms and definitions For the purposes of this document, the terms and definitions given in EN 14813-1:2006 apply. 4 Test classification Two levels of testing are detailed in this European Standard. TL1 is a simplified level that gives principle information about the functionality of the system. It does not aim to verify the comfort parameters and performance of the system. It can be done in a workshop or at a yard. TL2 is a full level test to verify the comfort parameters and the performance of the system. This test shall be performed in a climatic chamber or in an appropriate environment. The operator shall detail in his contractual specification the test classification.
