Designation: A192/A192M − 02 (Reapproved 2012) A192/A192M − 17
Standard Specification for
Seamless Carbon Steel Boiler Tubes for High-Pressure
Service
This standard is issued under the fixed designation A192/A192M; the number immediately following the designation indicates the year
of original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval.
A superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
This standard has been approved for use by agencies of the U.S. Department of Defense.
1. Scope Scope*
1.1 This specification covers minimum-wall-thickness, seamless carbon steel boiler and superheater tubes for high-pressure
service.
1.2 The tubing sizes and thicknesses usually furnished to this specification are ⁄2 in. to 7 in. [12.7 to 177.8 mm] outside diameter
and 0.085 to 1.000 in. [2.2 to 25.4 mm], inclusive, in minimum wall thickness. Tubing having other dimensions may be furnished,
provided such tubes comply with all other requirements of this specification.
1.3 Mechanical property requirements do not apply to tubing smaller than ⁄8 in. [3.2 mm] inside diameter or 0.015 in. [0.4 mm]
thickness.
1.4 The values stated in either inch-pound units or SI units are to be regarded separately as standard. Within the text, the SI units
are shown in brackets. The values stated in each system are not exact equivalents; therefore, each system must be used
independently of the other. Combining values from the two systems may result in nonconformance with the specification. The
inch-pound units shall apply unless the “M” designation of this specification is specified in the order.
1.5 This international standard was developed in accordance with internationally recognized principles on standardization
established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued
by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
2. Referenced Documents
2.1 ASTM Standards:
A450/A450M Specification for General Requirements for Carbon and Low Alloy Steel Tubes
3. Ordering Information
3.1 Orders for material under this specification should include the following, as required, to describe the desired material
adequately:
3.1.1 Quantity (feet, metres, or number of lengths),
3.1.2 Name of material (seamless tubes),
3.1.3 Manufacture (hot-finished or cold-finished),
3.1.4 Size (outside diameter and minimum wall thickness),
3.1.5 Length (specific or random),
3.1.6 Optional requirements (Section(Sections 88.1 and 10.4),
3.1.7 Test report required (see section on Certification of Specification A450/A450M),
3.1.8 Specification designation, and
3.1.9 Special requirements.
This specification is under the jurisdiction of ASTM Committee A01 on Steel, Stainless Steel and Related Alloys and is the direct responsibility of Subcommittee A01.09
on Carbon Steel Tubular Products.
Current edition approved Sept. 1, 2012Nov. 1, 2017. Published November 2012November 2017. Originally approved in 1936. Last previous edition approved in 20072012
as A192/A192MA192/A192M – 02 (2012).– 02(2007). DOI: 10.1520/A0192_A0192M-02R12.10.1520/A0192_A0192M-17.
For ASME Boiler and Pressure Vessel Code applications see related Specification SA-192 in Section II of that Code.
For referenced ASTM standards, visit the ASTM website, www.astm.org, or contact ASTM Customer Service at service@astm.org. For Annual Book of ASTM Standards
volume information, refer to the standard’s Document Summary page on the ASTM website.
*A Summary of Changes section appears at the end of this standard
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
A192/A192M − 17
4. General Requirements
4.1 Material furnished under this specification shall con-form to the applicable requirements of the current edition of
Specification A450/A450M, unless otherwise provided herein.
5. Manufacture
5.1 Tubes shall be made by the seamless process and shall be either hot-finished or cold-finished, as specified.
6. Heat Treatment
6.1 Hot-finished tubes need not be heat treated. Cold-finished tubes shall be heat treated after the final cold-finishing at a
temperature of 1200°F [650°C] or higher.
7. Chemical Composition
7.1 The steel shall conform to the following requirements as to chemical composition:
Carbon, % 0.06–0.18
Manganese, % 0.27–0.63
Phosphorus, max, % 0.035
Sulfur, max, % 0.035
Silicon, max, % 0.25
7.2 Supplying an alloy grade of steel that specifically requires the addition of any element other than those listed in 7.1 is not
permitted.
8. Product Analysis
8.1 When requested on the purchase order, a product analysis shall be made by the supplier f
...
