ASTM D7689-21

This document is not an ASTM standard and is intended only to provide the user of an ASTM standard an indication of what changes have been made to the previous version. Because
it may not be technically possible to adequately depict all changes accurately, ASTM recommends that users consult prior editions as appropriate. In all cases only the current version
of the standard as published by ASTM is to be considered the official document.
Designation: D7689 − 20 D7689 − 21
Standard Test Method for
Cloud Point of Petroleum Products and Liquid Fuels (Mini
Method)
This standard is issued under the fixed designation D7689; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
1. Scope*
1.1 This test method covers the determination of the cloud point of petroleum products, biodiesel, and biodiesel blends that are
transparent in layers 40 mm in thickness, using an automatic instrument.
1.2 This test method covers the range of cloud point temperatures from –50 °C to +6 °C.
1.3 The values stated in SI units are to be regarded as standard. No other units of measurement are included in this standard.
1.4 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility
of the user of this standard to establish appropriate safety, health, and environmental practices and determine the applicability of
regulatory limitations prior to use.
1.5 This international standard was developed in accordance with internationally recognized principles on standardization
established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued
by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
2. Referenced Documents
2.1 ASTM Standards:
D2500 Test Method for Cloud Point of Petroleum Products and Liquid Fuels
D4057 Practice for Manual Sampling of Petroleum and Petroleum Products
D4177 Practice for Automatic Sampling of Petroleum and Petroleum Products
D6708 Practice for Statistical Assessment and Improvement of Expected Agreement Between Two Test Methods that Purport
to Measure the Same Property of a Material
D6751 Specification for Biodiesel Fuel Blend Stock (B100) for Middle Distillate Fuels
2.2 Energy Institute Standard:
IP219 Test Method for Cloud Point of Petroleum Products
3. Terminology
3.1 Definitions:
This test method is under the jurisdiction of ASTM Committee D02 on Petroleum Products, Liquid Fuels, and Lubricants and is the direct responsibility of Subcommittee
D02.07 on Flow Properties.
Current edition approved June 1, 2020Jan. 1, 2021. Published June 2020January 2021. Originally approved in 2011. Last previous edition approved in 20172020 as
D7689 – 17.D7689 – 20. DOI:10.1520/D7689-20.DOI:10.1520/D7689-21.
For referenced ASTM standards, visit the ASTM website, www.astm.org, or contact ASTM Customer Service at service@astm.org. For Annual Book of ASTM Standards
volume information, refer to the standard’s Document Summary page on the ASTM website.
Available from Energy Institute, 61 New Cavendish St., London, WIG 7AR, U.K., http://www.energyinst.org.
*A Summary of Changes section appears at the end of this standard
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
D7689 − 21
3.1.1 biodiesel, n—fuel comprised of mono-alkyl esters of long chain fatty acids derived from vegetable oils or animal fats,
designated B100.
3.1.1.1 Discussion—
Biodiesel is typically produced by a reaction of a vegetable oil or animal fat with an alcohol such as methanol or ethanol in the
presence of a catalyst to yield mono-alkyl esters and glycerin, which is removed. The finished biodiesel derives approximately
10 % of its mass from the reacted alcohol. The alcohol used in the reaction may or may not come from renewable resources.
3.1.2 biodiesel blend, blend (BXX), n—blend of biodiesel fuel with diesel fuels and fuel oils.a homogeneous mixture of
hydrocarbon oils and mono-alkyl esters of long chain fatty acids.
3.1.2.1 Discussion—
In the abbreviation, BXX, the XX represents the volume percentage of biodiesel fuel in the blend.
3.1.2.2 Discussion—
The mono-alkyl esters of long chain fatty acids (that is, biodiesel) used in the mixture shall meet the requirements of Specification
D6751.
3.1.2.3 Discussion—
Diesel fuel, fuel oil, and non-aviation gas turbine oil are examples of hydrocarbon oils.
3.1.3 biodiesel fuel, n—synonym for biodiesel.
3.1.4 cloud point, n—in petroleum products and biodiesel fuels, the temperature of a liquid specimen when the smallest observable
cluster of wax crystals first occurs upon cooling under prescribed conditions.
3.1.4.1 Discussion—
The cloud point occurs when the temperature of the specimen is low enough to cause wax crystals to precipitate. In a homogeneous
liquid, the cloud is always noted first at the location in the specimen where the specimen temperature is the lowest. The cloud point
is the temperature at which the crystals first occur, regardless of their location in the specimen, and not after extensive
crystallization has taken place. The wax crystals that precipitate at lower temperatures are typically, but not excluded to,
straight-chain hydrocarbons and lipids.
3.2 Definitions of Terms Specific to This Standard:
3.2.1 D2500/IP219 equivalent cloud point, n—temperature of a specimen, in integers, calculated by applying a bias and rounding
the results of this test method to the next lower integer (see 12.2).
3.2.1.1 Discussion—
This test method produces results with 0.1 °C resolution. Should the user wish to provide results with a similar format to Test
Method D2500, then this calculation can be performed. Some apparatus can perform this calculation automatically.
3.2.2 mini method, n—in cloud point test methods, automatic test procedure using a small sample size, prescribed cooling rate,
specimen receptacle, and optical system for detection of crystal formation.
3.2.2.1 Discussion—
The prescribed cooling rate is described in 4.1, the specimen receptacle is described in 7.1, and the optical system for detection
of crystal formation is described in 4.1.
4. Summary of Test Method
4.1 After inserting the test specimen into the automatic apparatus, and initiation of the program, the test specimen is heated, if
necessary, to a starting temperature and then cooled by prescribed rates (11.5 and 11.6). The test specimen is continuously
monitored for appearance of hydrocarbon crystals with opposing light emitter and optical receiver (Annex A1). When the
crystallization in the specimen is detected by the optical system, the temperature is recorded to within 0.1 °C resolution. The
specimen is then heated to facilitate the start of the next test.
5. Significance and Use
5.1 The cloud point of petroleum products and biodiesel fuels is an index of the lowest temperature of their utility for certain
applications. Wax crystals of sufficient quantity can plug filters used in some fuel systems.
5.2 Petroleum blending operations require precise measurement of the cloud point.
D7689 − 21
5.3 This test method can determine the temperature of the test specimen at which wax crystals have formed sufficiently to be
observed as a cloud with a resolution of 0.1 °C.
5.4 This test method provides results that, when corrected for bias and rounded to the next lower integer (see 12.2), have been
found equivalent to Test Method D2500.
5.5 This test method determines the cloud point in a shorter time period than required by Test Method D2500.
6. Apparatus
6.1 Automated Apparatus —The apparatus consists of a microprocessor-controlled test specimen chamber that is capable of
heating and cooling the test specimen at required rates, optically observing the first appearance of hydrocarbon wax crystals, and
recording the temperature of the test specimen chamber. A detailed description of the apparatus is provided in Annex A1.
6.2 The apparatus shall be equipped with a thermostatically controlled specimen chamber, digital display, cooling and heating
systems, optical detection system, and a specimen chamber temperature measuring device.
6.3 The temperature-measuring device in the specimen chamber shall be capable of measuring the temperature, at minimum, from
–60 °C to 60 °C at a resolution of 0.1 °C.
7. Reagents and Materials
7.1 Specimen Vial—Disposable, clear glass cylinder with closed flat bottom, 1 mL capacity.
NOTE 1—Standard NWV type vial is suitable.
Dimensions:
Outer diameter: 8.08.0 mm to 8.3 mm
Wall thickness: 0.750.75 mm to 0.85 mm
Outer length: 39.2539.25 mm to 40.25 mm
7.2 Specimen Vial Stopper —Disposable, proprietary designed for use in this apparatus.
7.3 Micropipette—Capable of delivering 0.5 mL 6 0.1 mL of sample. Positive displacement-type micropipette with capillary
piston is preferred for use. Air displacement-type micropipettes are not recommended for viscous samples.
8. Sampling
8.1 Obtain a sample in accordance with Practice D4057 or D4177.
8.2 At least 1 mL of sample is required for each test.
8.3 Samples of very viscous materials may be warmed until they are reasonably fluid before they are tested. However, no sample
should be heated more than is absolutely necessary.
8.4 The sample shall not be heated above 60 °C. When the sample is heated above 60 °C, allow the sample to cool below 60 °C
before filtering or inserting into the apparatus.
8.5 When moisture is present, remove the moisture by a method such as filtration through dry, lint-free filter paper until the oil
is perfectly clear, but make such filtration at a temperature at least 14 °C above the expected cloud point.
The sole source of supply of the apparatus (ISL Model MPP 5Gs analyzer) known to the committee at this time is ISL, B.P. 70825 14653, Verson, France. If you are
aware of alternative suppliers, please provide this information to ASTM International Headquarters. Your comments will receive careful consideration at a meeting of the
responsible technical committee, which you may attend.
D7689 − 21
NOTE 2—Moisture will be noticed in the sample as a separate phase or as a haze throughout the entire sample. Generally, a slight haze will not interfere
with the detection of the wax cloud.
9. Preparation of Apparatus
9.1 Prepare the instrument for operation in accordance with the manufacturer’s instructions.
10. Calibration and Standardization
10.1 Ensure that all of the manufacturer’s instructions for calibrating, checking, and operating the apparatus are followed.
10.2 A sample with a well-documented cloud point can be used to verify the performance of the automatic apparatus.
Alternatively, a sample that has been extensively tested
...
